Chapter 2: Pin Definition & Jumper Settings
2-1 Front Panel Pin Definition
1. Power Switch
2. LAN port
3. Two RS-232 ports (COM1 & COM2)
Pin Def initi on Pin Definition
1 DCD 2 RX
3 TX 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI
4. Two USB por ts
Pin Definition
1 5V
2 D -
3 D+
4 G ND
5. Power & HDD ON/Off LED
- Power LED indicator would li ght when power is on.
- HDD LED indicator for hard disk access is an active low signal.
2-2 Top & Bottom Panel Pin Definition
1. One DR-9 reser ved for Top & Bottom panel as optional expansion.
