http://www.accusys.com.tw 15
User’s Manual
2.5.2 RAID Configuration
1.
Click Configuration form Monitor Windows
and the Enter Password dialog box pops
out on the screen.
2. You will be prompted to enter the
Password. The default password is 0000
(four zeros). Click Ok, the Configure
Setting dialog box will appear.
3. Configure Setting include Quick Setup
RAID and Change password.
2.5.2.1 Quick Setup RAID
1.
Click Quick Setup RAID and the RAID
level setting dialog box will appear.
Current RAID level : RAID level at present
Current controller no : RAID Box number
Select stripe size : stripe size at present
Supported RAID Level : Display which RAID
level you can select.
Click OK to process the Quick Setup RAID.
Caution
During the expansion process, please don’t turn off the
system or pull out disk.
Note
If set up the state of the disk into a Dynamic disk, the expand
function only can be use in 2R0 to R5.
