2.4. Monitoring RAID status with StorConn

The StorConn browser allows you to remotely monitor the status of your RAID in real time.

2.4.1. Remotely monitor StorConn

Open a browser on an Internet-connected computer.
Enter the url http://ip:web server port where ip is the IP address determined in Installing
StorConn above, web server port is the System Configuration Setup.

The StorConn browser window displays the following information:

1. RAID box tab: Allow customer to select which RAID to monitor.
2. RAID box information: Lists model name, serial number and current RAID level.
3. Disk status: Allows you to monitor the status of each of the disk drives.
4. Disk information: Lists model name and capacity of each of the disk drives.
5. Re-build / initialize progress: Tracks the re-building or initialization process.
6. Fan Status: Display the status of fan.

Note

Java Runtime Environment must be installed for StorConn to be
successfully displayed on a browser and JRE version must be
5.0 or later. If JRE is not already installed, the application can
be downloaded free from http://java.sun.com/downloads/
