Tabelle 1. Daten von Standardrollnuten
Hinweis: Alle Maße in Zoll.
Nenn-
rohr-
größe
Rohr-
durchmesser
A.D.
Tol.
T
Min.
Wand-
stärke
A
Dicht-
fl äche
± .030
B
Nut-
breite
± .030
C
Nut-
durchmesser
A.D.
Tol.
D
Nenn-
nut-
tiefe
D
Min.
Nut-
tiefe
1 1.315
+.016
-.031
.065
.625
.281
1.190 +.000
-.015
.063 .047
1 1/4
1.660
+.016
-.031
.065
.625
.281
1.535
+.000
-.015
.063
.047
1 1/2
1.900
+.016
-.031
.065
.625
.281
1.775
+.000
-.015
.063
.047
2
2.375 ±
.024
.065
.625 .344
2.250
+.000
-.015
.063
.051
2 1/2
2.875
± .029
.083
.625
.344
2.720
+.000
-.018
.078
.063
3
3.50
± .035
.083
.625
.344
3.344
+.000
-.018
.078
.060
3 1/2
4.00
± .040
.083
.625
.344
3.834
+.000
-.020
.083 .063
4
4.50 ±
.045
.083
.625 .344
4.334
+.000
-.020
.083
.060
5
5.563
± .056
.109
.625
.344
5.395
+.000
-.022
.084
.056
6
6.625 ±
.060
.109
.625
.344
6.455
+.000
-.022
.085
.052
8
8.625
± .086
.109
.750
.469
8.441
+.000
-.025
.092
.049
10
10.75
± .108
.134
.750
.469
10.562
+.000
-.027
.094
.040
12
12.75 ±
.128 .165
.750
.469
12.531
+.000
-.030
.110
.045
Tabelle 2. Maximale und minimale Rohrwandstärken
Rohrgröße
Kohlenstoffstahl- oder Aluminiumleitung
oder -rohr
Edelstahlleitung oder -rohr
PVC-/CPVC-Rohr
Wandstärke
Wandstärke
Wandstärke
Min.
Max.
Min.
Max.
Min.
Max.
1”
.065
.133
.065
.133
.133
.133
1 1/4”
.065
.140
.065
.140
.140
.191
1 1/2”
.065
.145
.065
.145
.145
.200
2”
.065
.154
.065
.154
.154
.154
2 1/2”
.083
.203
.083
.188
.203
.276
3”
.083
.216
.083
.188
.216
.300
3 1/2”
.083
.226
.083
.188
.226
.318
4”
.083
.237
.083
.188
.237
.337
5”
.109
.258
.109
.188
.258
.375
6”
.109
.280
.109
.188
.280
.432
8”
.109
.322
.109
.188
.322
.322
10”
.134
.307
.134
.188
.365
.365
12”
.165
.330
.165
.188
.406
.406
