Hardware: Hardware shown is actual size

(2) Wire Tie Clip - f

(5) Wire Tie -g*

(4) Lag Bolt - h

(4) Lag Bolt Washer - i

(1) Allen Key - j

(4) 2” Carriage Bolt - k

(4) 1/4-20 Nut - l

(2) Safety Bolt - m

Supplied Television Mounting Hardware: Hardware shown is actual size

(4) M4 x 12mm Bolt - n (4) M5 x 12mm Bolt - o (4) M6 x 12mm Bolt - p

(4) M8 x 16mm Bolt - q

(4) M4 x 30mm Bolt - r (4) M5 x 30mm Bolt - s (4) M6 x 35mm Bolt - t (4) M8 x 40mm Bolt - u

(4) M4 Lock Washer - v (4) M5 Lock Washer - w (4) M6 Lock Washer - x (4) M8 Lock Washer - y

(4) M4/M5 Spacer - z

(4) M6/M8 Spacer - aa (8) M4/M5 Washer - bb (4) M6/M8 Washer - cc
