43
Field Description
IP Address
Enter the IP address of LAN interface. It is
recommended to use an address from a block that is
reserved for private use. This address block is
192.168.2.1- 192.168.255.254.
Subnet Mask
Enter the subnet mask of LAN interface. The range of
subnet mask is from 255.255.0.0-255.255.255.254.
Secondary IP
Select this to enable the secondary LAN IP address.
The two LAN IP addresses must be in the different
networks.
LAN Port
You can choose the LAN interface you want to
configure.
Link
Speed/Duplex
Mode You can select the following modes from the drop-
downlist:100Mbps/FullDuplex,100Mbps/Half
Duplex,10Mbps/FullDuplex,10Mbps/Half
