68
MAC Address Input the MAC address of other WDS-enabled
access point.
Comment Input any descriptive text about this MAC address,
so you can remember the purpose of this MAC
address. You can input up to 20 alphanumerical
characters in this field.
Apply Changes Click this button to add above MAC address and
comment to WDS access point list.
Reset Clear the contents of ‘MAC Address’ and
Comment’ field.
Set Security Click this button to set WDS security (encryption).
All WDS access points must use the same
security setting so they can communicate with
each other.
Please refer to chapter 2-7-3 for detailed
instructions about how to input proper encryption
parameters.
Show Statistics Click this button and a new window with all
statistics (Tx / Rx packet counts, error counts etc.)
will appear. Click ‘Close’ to close the window.
Please note: If your browser prevents pop-up
window from appearing, please disable this
function or you will not be able to use 'Show
Statistics' function.
All WDS AP addresses in the list will be listed in ‘Current WDS List’ table:
If you want to delete one or more AP(s) listed here, check ‘Select’ box of the
AP(s) you wish to delete, then click ‘Delete Selected’ button; Click ‘Delete All’
to delete all AP. If you want to unselect all selected boxes, click ‘Reset’ button.
