33
use this IP address.
IP Address Input the IP address assigned by your Internet
Service Provider.
Subnet Mask Input the Subnet Mask assigned by your Internet
Service Provider.
Server IP Address Input the IP address of L2TP connection server.
User Name Input the user name of L2TP connection server.
Password Input the password of L2TP connection server.
When you finish, click ‘Next’ to continue.
6. Please select the wireless band and mode here:
Item Name Description
Band Select the wireless band:
2.4GHz (B): only wireless clients with 802.11b
capability can connect to this router. Maximum
connection speed is 11Mbps.
2.4GHz (G): only wireless clients with 802.11g
capability can connect to this router. Maximum
connection speed is 54Mbps.
