84 C HAPTER 3: C ONFIGURING W IRELESS S ERVICES
Table 12 Creating a Service for VoWIP Access
Task Path Primary Parameters to Configure
“Create a Radio Profile”
on page 56 1 Tool bar option: select
Configuration.
2 Organizer panel: expand the
WX switch.
3 Expand Wireless.
4 Click Radio Profiles.
5 Select Radio Profile in the Task
List.
From the Create Radio Profile wizard:
„
Radio profile name: enter a name
For SpectraLink, from the Radio Profile Properties
dialog:
„
802.11 attributes: change DTIM to 3
After you create the service profile, you can map it
to the radio profile.
After you install the MAPs, you can map their radios
to the radio profile.
Note: The examples in this chapter configure the
radio profile first. However, you also can configure
the radio profile later as part of service profile
configuration.
“Create a Service Profile
for Voice” on page 86 1 Tool bar option: select
Configuration.
2 Organizer panel: expand the
WX switch.
3 Expand Wireless.
4 Click Wireless Services.
5 Select Voice Service Profile in
the Task List.
From the Create Service Profile wizard:
„
Service profile name: edit name
„
SSID name: enter name
„
SSID Type: use Clear (unencrypted)
„
VLAN Name: enter name
„
Authentication server: select LOCAL
„
Radio profile: select one
“Set Up a VLAN for
VoWIP on WX Switches”
on page 94 1 Tool bar option: select
Configuration.
2 Organizer panel: expand the
WX switch.
3 Expand System.
4 Click VLANs.
5 Select VLAN in the Task List.
From the Create VLAN wizard:
„
VLAN Name: enter name
„
VLAN ID: select number
„
IP Address: enter IP Address
„
Ports: select them and move them to the voice
VLAN
For SpectraLink, from the VLAN Properties dialog:
„
IGMP: disable
SVP requires IGMP snooping to be disabled.
