C
HAPTER
6:
M
ONITORING THE
V7111
The V7111 provides several ways of monitoring the status of the gateway:
Monitoring the V7111 front panel LEDs (see
Monitoring the V7111 Front Panel LEDs
Monitoring the V7111 channels via the Embedded Web Server (see
).
Monitoring the V7111 Front Panel LEDs
The V7111 front panel LEDs indicate the Ethernet LAN status, Data (RTP) activity and state
of the gateway ports.
and
describe the meaning of each state of the LEDs
on the front panel.
Table 10
Definition of V7111 Front Panel LED Indicators
LED Type Color
State
Definition
On
Device powered, self-test OK
Device
Status
Ready
Green
Off
Software loading or System failure
On
Valid 10/100 Base-TX Ethernet connection
Ethernet
Link Status
Uplink
Green
Off No
uplink
On
Power is currently being supplied to the device
Power
Supply
Status
Power
Green
Either there’s a failure / disruption in the AC power
supply or power is currently not being supplied to the
device through the AC power supply entry.
Off
Failure (fatal error).
Or system initialization.
On
Failure
Indication
Fail
Red
Off Normal
working
condition
Blinking
The phone is ringing (incoming call, before answering).
Fast
Blinking
Line malfunction
Off
Normal onhook position
Channels
Status
Telephone
Interface
Green
On
Offhook
