zt1100/xz200 and xt1500 Series Removing and Replacing Parts 41
Troubleshooting and Self-Repair Guide
Removing the Optical Drive Module
Table 2. Optical Drive Module Replacement Part Numbers
Description Part Number Exchange Part Number
Drive, DVD module F3398-60911
Drive, DVD/CD-RW Combo module F3398-60912
Required Equipment
• None.
Removal Procedure
• Slide the module release latch in the direction shown by the arrow on the latch, and remove the
module.
Figure 9. Releasing the Plug-in Module
