C T
ECHNICAL
S
PECIFICATIONS
Physical Dimensions Height: 43.6mm x Width: 440mm x Depth: 247.5mm
Weight: 5kg (11lbs)
Environmental Requirements
Operating Temperature 0° to 50°C (32° to 122°F)
Storage Temperature –10° to +70°C (14° to 158°F)
Operating Humidity 10–95% relative humidity, non-condensing
Standards EN60068 (IEC68) — various parts
Safety
Agency Certifications UL 1950, EN60950, CSA 22.2 No. 950, IEC 60950
EMC
Emissions EN55022 Class A, FCC Part 15 subpart B Class A, ICES-003 Class A,
VCCI Class A, AS/NZS 3548 Class A, CNS 13438 Class A
Immunity EN50082-1
Heat Dissipation 75 watts maximum
Power Supply
AC Line Frequency 50/60Hz
Input Voltage Options 90–240 VAC
Current Rating 3amps (maximum)
(continued)
