Network Configuration Examples 17
Network
Configuration
Examples The following illustrations show some examples of how the Switch can be
used in your network.
Switch 3300 MM as a
Segmentation Switch
The example in Figure 3 shows how a Switch 3300 MM stack can
segment a network of shared 10Mbps and 100Mbps connections. There
is a 10/100 shared segment on each floor, and these segments are
connected to the Switch which is positioned in the basement.
Figure 3 Using the Switch to segment your network
Dual Speed Hub 500
Dual Speed Hub 500
Endstations on shared 10Mbps
and 100Mbps connections
Endstations on shared 10Mbps
and 100Mbps connections
Endstations and servers on switched
10Mbps and 100Mbps connections
Local server on a shared
100Mbps connection
Local server on a shared
100Mbps connection
100Mbps
Switch 1100/3300
Switch 3300 MM
