Page 6 Document Centre Technical Support Operations
Feature Implementation Values
Resolution
600 x 600 x 1
1200 x 1200 x 1
1800 x 1800 x 1
600 x 600 x 2
<<< /Type 4 /ValuesPerColorComponent 2
>>
/HWResolution [x y]>> setpagedevice
<<< /Type 4 /ValuesPerColorComponent 4
>>
/HWResolution [x y]>> setpagedevice
Where x and y are one of the following:
600 600
1200 1200
1800 1800
Quantity <>setpagedevice
OR
%% OID_ATT_COPY_COUNT value Where int or value is 1 to 9999
Simplex <> setpagedevice Where value is false
Duplex Long Edge
Binding <>
setpagedevice Where value is false
Duplex Short Edge
Binding <>
setpagedevice Where value is true
Landscape
Orientation <>
setpagedevice [height/width] in 1/72 inch (points)
To print landscape, use the Media Size
command with height and width reversed. For
example:
[792 612] = Letter, landscape
[842 595] = A4, landscape
For landscape documents printed on 11 x 17",
8.5 x13", 8.5 x 14" or A3, apply a 180° rotation to
landscape pages to ensure the correct location of
stapling or punching.
Use the PostScript command: "0 0 moveto 180
rotate -height -width translate" which should
appear after any "setpagedevice" commands.
The following example, for an A3 landscape page
illustrates this syntax.
<> setpagedevice
…any other "setpagedevice" commands.
0 0 moveto 180 rotate -1191 -842 translate
…rest of print commands for page.
Force short edge
feeding %%OID_ATT_FEED_EDGE value;
or
<< /LeadingEdge int >> setpagedevice
Where value is one of the following:
For portrait documents use:
OID_VAL_FEED_EDGE_SHORT_TRAILING
For landscape documents use:
OID_VAL_FEED_EDGE_SHORT_LEADING
Where int is one of the following:
For portrait documents use: 2
For landscape documents use: 0
NOTE: The following media sizes default to printing
with the long-edge fed first: Letter, Letter Cover,
Statement, Executive, 8 x 10", A4, A4 Cover and
B5. It is possible to force these media sizes to print
with short-edge first.
