Document Centre Technical Support Operations
Feature
Implementation
Values
Media Type
@PJL COMMENT
OID_ATT_DEFAULT_MEDIUM_TYPE
“value”
Where value is one of the following:
bond, letterhead, standard, transparency, labels,
drilled, recycled, preprinted, cardstock, other,
system-default, envelopes, tabs, Custom1 –
Custom7
NOTE: Use this command in conjunction with
these commands: Media Size and Media Color.
Media Color
@PJL COMMENT
OID_ATT_DEFAULT_MEDIUM_ COLOR
“value”
Where value is one of the following:
buff, blue, clear, gray, green, ivory, orange,
other, pink, red, white, yellow, goldenrod,
unspecified, Custom1 - Custom 7.
NOTE: Use this command in conjunction with
these commands Media Size and Media Type.
Media Source
l int H
Where int is one of the following:
0 = Auto Select
1 = Tray 1
4 = Tray 2
23 = Tray 3 (High Capacity)
24 = Tray 4 (High Capacity)
2 = Bypass Tray
NOTE: See the media selection comments in the
Dependencies / Caveats section.
Output Location –
Options supported
depend on output device.
@PJL COMMENT
OID_ATT_OUTPUT_BINS value
Where value can be one of the following:
With a catch tray:
OID_VAL_OUTPUT_BIN_SIDE
With a 2000 Sheet Stapler/Stacker (Office
Finisher)
OID_VAL_OUTPUT_BIN_TOP
OID_VAL_OUTPUT_BIN_STACKER
NOTE: You cannot use the finisher stacker tray
with envelopes and labels. Stapling or punching
requires use of the stacker tray. If you indicate an
invalid combination of commands, the output
location request is ignored.
Stapling
@PJL COMMENT OID_ATT_FINISHING
OID_VAL_FINISHING_STAPLE;
@PJL COMMENT XRXSTAPLE = value
Where value is one of the following:
PORTRAIT
LANDSCAPE
DUAL
Refer to the "Single Staple Location" table later in
this document, for information about staple
location restrictions.
Hole Punching
@PJL COMMENT OID_ATT_PUNCH int;
Where int is one of the following:
0 = No Punch
1 = Punch each page
NOTE: You can only use the optional hole
punching command with 8.5 x 11", 11 x 17", 9 x
11", A4, A3 and A4 cover size media. Use the
"rotated landscape" orientation with 11 x 17" and
A3 pages.
Collation
@PJL COMMENT OID_ATT_OUTPUT
value;
Where value is one of the following:
OID_VAL_OUTPUT_PAGE_COLLATE
OID_VAL_OUTPUT_NO_PAGE_COLLATE
Resolution
@PJL SET RESOLUTION = value;
Where value is the following:
600
