ZyXEL Communications Prestige 650H-E Series User Manual
Page 11
Prestige 650H-E
11
Figure 7 Internet Connection with PPPoE
If your ISP provides the name of your
PPPoE service provider, enter it in the
Service Name field.
Enter the user name and password exactly
as your ISP assigned them.
Select Obtain an IP Address
Automatically if you have a dynamic IP
address; otherwise select Static IP Address
and type your ISP assigned IP address in
the text box below.
Select Connect on Demand when you don't
want the connection up all the time and
specify an idle time-out period (in seconds)
in the Max. Idle Timeout field.
Select Nailed-Up Connection when you
want your connection up all the time. The
Prestige will try to bring up the connection
automatically if it is disconnected.
From the Network Address Translation drop-down list box, select SUA Only, Full Feature or None. Refer to
the Network Address Translation section for more information.
Figure 8 Internet Connection with RFC 1483
Enter the IP address given by your ISP in
the IP Address field.
The IP Address field is
not available for bridge
mode.
Refer to Figure 7 for description of the
Network Address Translation field.
