036-21217-001-B-1203
6 Unitary Products Group
NOTE: Cooling performance is rated at 80∞F dry bulb 67∞F wet bulb entering air temperature, CFM listed, 85∞F entering
95∞F leaving water temperature, and water flow rate listed. Gross capacity does not include the effect of evapora-
tor fan motor heat.
TABLE 3: GENERAL DATA CU 300 25 TON VERTICAL MODELS
Model CU300
Nominal Cooling(Ton) 25
Cooling Performance
Gross Cooling Capacity(Btuh)
322000
Design CFM 10000
EER 11.5
Compressor-Type Scroll
Number Used 3
Evaporator Coil-Type Copper Tubes, Aluminum Fins
Face Area(sq ft) 19.79
Rows/FPI 4/12
Condenser-Type Coaxial
Number Used/Tons Capacity 3/7.5
Nominal Water flow rate (gpm) 78
Unit Water Connection Size 2 in FPT
Evaporator Fan-Type Centrifugal, Forward Curved
Number Used 2
Diameter x Width (in) 15x11
Drive Adjustable Belt
Motor HP (Standard/Oversize) 7.5/10
Filters
Number Used-Size(in)
8-20x20x2
Condensate Drain Connection 3/4FPT
Weight
Shipping
1825
