York SINGLE PACKAGE AIR CONDITIONING CH060 - Manual (Page 12)

036-21217-001-B-1203
12 Unitary Products Group
TABLE 10: COOLING PERFORMANCE DATA - CU 5-20 TON VERTICAL MODELS
CU060
5 TON
2000 CFM
9 GPM 15 GPM
EWT EWT
65∞F 85∞F 105∞F 65∞F 85∞F 105∞F
EWB EDB TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW
62∞F
75∞F 62.1 48.9 2.87 58.3 47.2 3.65 54.4 45.4 4.67 63.1 49.4 2.71 59.2 47.5 3.45 62.1 48.9 2.87
80∞F 62.1 58.2 2.87 58.3 57.0 3.65 54.4 54.1 4.67 63.1 58.7 2.71 59.2 56.7 3.45 62.1 58.2 2.87
85∞F 65.4 65.4 2.91 61.5 61.5 3.71 57.8 57.8 4.74 66.3 66.3 2.74 62.5 62.5 3.53 65.4 65.4 2.91
67∞F
75∞F 66.4 38.1 2.93 62.0 36.9 3.71 57.2 34.9 4.70 67.6 39.3 2.75 63.3 37.5 3.49 66.4 38.1 2.93
80∞F 66.4 48.0 2.93 62.0 46.2 3.71 57.2 44.3 4.70 67.6 48.5 2.75 63.3 46.7 3.49 66.4 48.0 2.93
85∞F 66.4 57.8 2.93 62.0 55.7 3.71 57.2 53.7 4.70 67.6 58.4 2.75 63.3 56.3 3.49 66.4 57.8 2.93
72∞F
75∞F 71.4 28.7 2.99 66.6 27.4 3.77 61.4 25.5 4.77 72.7 29.1 2.79 68.0 28.0 3.53 71.4 28.7 2.99
80∞F 71.4 38.1 2.99 66.6 36.2 3.77 61.4 34.3 4.77 72.7 38.6 2.79 68.0 36.8 3.53 71.4 38.1 2.99
85∞F 71.4 47.3 2.99 66.6 45.6 3.77 61.4 43.7 4.77 72.7 47.8 2.79 68.0 46.1 3.53 71.4 47.3 2.99
CU096
8 TON
3200 CFM
15 GPM 24 GPM
EWT EWT
65∞F 85∞F 105∞F 65∞F 85∞F 105∞F
EWB EDB TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW
62∞F
75∞F 99.0 78.9 4.44 93.9 76.4 5.65 87.2 73.4 7.22 100.3 79.3 4.21 94.9 76.8 5.38 99.0 78.9 4.44
80∞F 99.0 93.9 4.44 93.9 91.5 5.65 87.2 87.2 7.22 100.3 94.7 4.21 94.9 92.0 5.38 99.0 93.9 4.44
85∞F 104.2 104.2 4.50 98.8 98.8 5.71 92.4 92.4 7.32 105.4 105.4 4.25 100.0 100.0 5.44 104.2 104.2 4.50
67∞F
75∞F 105.9 62.3 4.47 99.1 59.4 5.69 91.4 56.2 7.26 107.3 62.9 4.24 100.6 60.1 5.41 105.9 62.3 4.47
80∞F 105.9 77.5 4.47 99.1 74.6 5.69 91.4 71.5 7.26 107.3 78.0 4.24 100.6 75.2 5.41 105.9 77.5 4.47
85∞F 105.9 93.2 4.47 99.1 90.2 5.69 91.4 86.8 7.26 107.3 93.8 4.24 100.6 91.0 5.41 105.9 93.2 4.47
72∞F
75∞F 113.6 45.7 4.54 106.5 43.9 5.76 98.3 40.9 7.33 115.3 46.4 4.28 108.2 44.7 5.43 113.6 45.7 4.54
80∞F 113.6 61.2 4.54 106.5 58.4 5.76 98.3 55.3 7.33 115.3 61.8 4.28 108.2 59.1 5.43 113.6 61.2 4.54
85∞F 113.6 76.3 4.54 106.5 73.6 5.76 98.3 70.6 7.33 115.3 76.9 4.28 108.2 74.3 5.43 113.6 76.3 4.54
CU120
10 TON
4000 CFM
18 GPM 30 GPM
EWT EWT
65∞F 85∞F 105∞F 65∞F 85∞F 105∞F
EWB EDB TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW
62∞F
75∞F 125.4 99.6 5.76 118.8 96.6 7.32 109.7 92.5 9.35 127.3 100.6 5.43 120.4 97.3 6.93 125.4 99.6 5.76
80∞F 125.4 118.6 5.76 118.8 115.4 7.32 109.7 109.7 9.35 127.3 119.6 5.43 120.4 116.7 6.93 125.4 118.6 5.76
85∞F 132.4 132.4 5.86 125.2 125.2 7.52 117.0 117.0 9.48 134.2 134.2 5.47 127.1 127.1 7.07 132.4 132.4 5.86
67∞F
75∞F 134.2 78.9 5.86 125.7 75.3 7.43 115.8 71.2 9.41 136.5 79.9 5.50 127.8 76.1 6.98 134.2 78.9 5.86
80∞F 134.2 98.0 5.86 125.7 94.4 7.43 115.8 90.5 9.41 136.5 98.9 5.50 127.8 95.4 6.98 134.2 98.0 5.86
85∞F 134.2 117.7 5.86 125.7 114.0 7.43 115.8 109.7 9.41 136.5 118.8 5.50 127.8 114.8 6.98 134.2 117.7 5.86
72∞F
75∞F 144.4 58.1 5.98 134.4 55.7 7.55 124.4 52.0 9.55 147.0 58.8 5.53 137.5 55.6 7.08 144.4 58.1 5.98
80∞F 144.4 77.6 5.98 134.4 73.8 7.55 124.4 69.9 9.55 147.0 78.5 5.53 137.5 75.0 7.08 144.4 77.6 5.98
85∞F 144.4 96.6 5.98 134.4 93.0 7.55 124.4 89.3 9.55 147.0 97.9 5.53 137.5 94.1 7.08 144.4 96.6 5.98
CU180
15 TON
6000 CFM
27 GPM 45 GPM
EWT EWT
65∞F 85∞F 105∞F 65∞F 85∞F 105∞F
EWB EDB TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW
62∞F
75∞F 185.2 146.0 9.14 175.0 141.3 11.25 163.0 136.1 14.03 187.5 147.0 8.65 177.4 142.3 10.64 185.2 146.0 9.14
80∞F 185.2 173.9 9.14 175.0 169.7 11.25 163.0 162.4 14.03 187.5 175.3 8.65 177.4 170.2 10.64 185.2 173.9 9.14
85∞F 194.6 194.6 9.41 184.8 184.8 11.54 172.8 172.8 14.28 197.8 197.8 8.90 187.8 187.8 10.94 194.6 194.6 9.41
67∞F
75∞F 197.2 115.5 9.37 185.0 110.4 11.44 171.2 104.5 14.24 200.6 116.8 8.87 188.6 111.8 10.80 197.2 115.5 9.37
80∞F 197.2 143.0 9.37 185.0 138.1 11.44 171.2 132.6 14.24 200.6 144.3 8.87 188.6 139.7 10.80 197.2 143.0 9.37
85∞F 197.2 172.2 9.37 185.0 166.8 11.44 171.2 161.0 14.24 200.6 173.9 8.87 188.6 168.5 10.80 197.2 172.2 9.37
72∞F
75∞F 211.5 86.3 9.66 198.2 81.1 11.75 183.5 75.4 14.56 215.4 88.1 9.11 202.4 82.8 11.03 211.5 86.3 9.66
80∞F 211.5 109.5 9.66 198.2 104.4 11.75 183.5 98.8 14.56 215.4 111.1 9.11 202.4 105.9 11.03 211.5 109.5 9.66
85∞F 211.5 134.1 9.66 198.2 129.1 11.75 183.5 123.6 14.56 215.4 135.6 9.11 202.4 130.6 11.03 211.5 134.1 9.66
CU240
20 TON
8000 CFM
36 GPM 60 GPM
EWT EWT
65∞F 85∞F 105∞F 65∞F 85∞F 105∞F
EWB EDB TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW
62∞F
75∞F 236.4 174.8 12.57 223.8 169.5 15.22 207.2 162.4 18.63 239.5 176.1 12.07 226.6 170.7 14.56 236.4 174.8 12.57
80∞F 236.4 207.6 12.57 223.8 202.3 15.22 207.2 195.1 18.63 239.5 208.9 12.07 226.6 203.4 14.56 236.4 207.6 12.57
85∞F 240.6 240.6 12.70 229.8 229.8 15.27 217.8 217.8 18.86 242.6 242.6 12.85 231.8 231.8 14.66 240.6 240.6 12.70
67∞F
75∞F 256.6 139.3 12.97 243.0 134.1 15.53 226.0 128.0 19.00 259.5 140.5 12.41 246.8 135.7 14.84 256.6 139.3 12.97
80∞F 256.6 171.9 12.97 243.0 166.8 15.53 226.0 160.8 19.00 259.5 173.1 12.41 246.8 168.5 14.87 256.6 171.9 12.97
85∞F 256.6 204.6 12.97 243.0 199.5 15.53 226.0 193.7 19.00 259.5 205.8 12.45 246.8 201.2 14.87 256.6 204.6 12.97
72∞F
75∞F 277.9 103.3 13.45 263.3 98.5 16.04 245.3 92.5 19.46 281.7 105.0 12.83 268.0 100.1 15.25 277.9 103.3 13.45
80∞F 277.9 135.8 13.45 263.3 131.2 16.04 245.3 125.5 19.46 281.7 138.2 12.83 268.0 133.0 15.25 277.9 135.8 13.45
85∞F 277.9 168.2 13.45 263.3 163.9 16.04 245.3 158.4 19.46 281.7 171.4 12.83 268.0 165.8 15.25 277.9 168.2 13.45
