036-21359-001-B-0302
Unitary Products Group 11
DUCT COVERS - Units are shipped with the bottom
duct openings covered. An accessory flange kit is available for
connecting side ducts.
For bottom duct applications:
1
Remove the side panels from the supply and return air
compartments to gain access to the bottom supply and
return air duct covers.
2 Remove and discard the bottom duct covers. (Duct
openings are closed with sheet metal covers except
when the unit includes a power exhaust option. The
covering consists of a heavy black paper composition.)
3 Replace the side supply and return air compartment
panels.
For side duct applications;
1
Replace the side panels on the supply and return air
compartments with the accessory flange kit panels.
2 Connect ductwork to the duct flanges on the rear of the
unit.
SUPPLY
AIR
RETURN
AIR
OUTDOOR
AIR
5-1/8"
18-5/8"
27-3/4"
29-5/8" (15 TON)
39-5/8" (20 TON)
40-1/2"
OUTDOOR AIR
COMPARTMENT
ACCESS
FILTER
ACCESS
1" NPT FEMALE
COND. DRAIN
CONNECTION
DOT PLUG
(For pressure
drop reading)
EVAPORATOR
SECTION
CONDENSER
SECTION
GAUGE LINE
ACCESS
40-3/8"
5-1/2"
COMPRESSOR
ACCESS
SUPPLY AIR
ACCESS
RETURN AIR
ACCESS
REAR
VIEW
S U P P L Y A I R
C O M P A R T M E N T
P O W E R E X H A U S T
R A I N H O O D
( o n R e t u r n A i r C o m p a r t m e n t )
E C O N O M I Z E R
M O T O R I Z E D
D A M P E R
R A I N H O O D
( o n O u t d o o r A i r C o m p a r t m e n t )
E C O N O M I Z E R / M O T O R I Z E D D A M P E R
A N D P O W E R E X H A U S T R A I N H O O D S
F I X E D
O U T D O O R A I R
I N T A K E H O O D
( l o c a t e d o n
R e t u r n A i r
C o m p a r t m e n t )
1 " C O N D E N S T A T E
D R A I N
( M u s t b e t r a p p e d )
R E A R V I E W L H V I E W
D E T A I L " Y "
U N I T W I T H R A I N H O O D S
3 6 "
6 6 - 1 / 2 "
9 2 " 3 6 - 1 / 4 "
5 "
3 4 - 1 / 4 "
1 6 - 1 / 8 "
2 "
