Chapter 4 Station Mode
NWD-270N User’s Guide
50
Figure 34 Security Setting: WPA-PSK/WPA2-PSK
The following table describes the labels in this screen.
4.4.1.4 WPA/WPA2
The screen that displays when you select WPA or WPA2 differs, depending on the EAP Type
you select (TLS, PEAP or TTLS).
Figure 35 Security Settings: WPA/WPA2
Table 10 Security Setting: WPA-PSK/WPA2-PSK
LABEL
DESCRIPTION
Encryption Type
The encryption mechanisms used for WPA/WPA2 and WPA-PSK/WPA2-PSK are
the same. The only difference between the two is that WPA-PSK/WPA2-PSK uses
a simple common password, instead of user-specific credentials.
Select the encryption type (TKIP or AES) for data encryption.
Refer to
Section 3.3.1.3 on page 34
for more information.
Pre-Shared Key
Type a pre-shared key (same as the AP or peer device) of between 8 and 63
case-sensitive ASCII characters (including spaces and symbols) or 64
hexadecimal characters.
Back
Click Back to go to the Site Survey screen to select and connect to another
network.
Next
Click Next to confirm your selections and advance to the Summary screen. Refer
to
.
Exit
Click Exit to return to the Site Survey screen without saving.
