Appendix B Windows Wireless Management
NWD-270N User’s Guide
115
Figure 86 Windows XP SP2: WZC Not Available
Connecting to a Wireless Network
1 Double-click the network icon for wireless connections in the system tray to open the
Wireless Network Connection Status screen.
Figure 87 Windows XP SP2: System Tray Icon
The type of the wireless network icon in Windows XP SP2 indicates the status of the NWD-
270N. Refer to the following table for details.
2 Windows XP SP2: In the Wireless Network Connection Status screen, click View
Wireless Networks to open the Wireless Network Connection screen.
Table 33 Windows XP SP2: System Tray Icon
ICON DESCRIPTION
The NWD-270N is connected to a wireless network.
The NWD-270N is in the process of connecting to a wireless network.
The connection to a wireless network is limited because the network did not assign a
network address to the computer.
The NWD-270N is not connected to a wireless network.
