Section 2. Installation
Overview
provides recommendations and procedures for inspecting, installing, and
testing the power supply. For more information about controls and connectors, refer
to the front panel diagram (
) as well as the rear panel diagram (
)
in
.
Basic Setup Procedure
provides a summary of the setup procedure and an overview of the
subsections in this chapter. Use this table as a quick reference if you are familiar with
the installation requirements for the power supply. If you require more information,
each step in the table refers to a subsequent section which contains more details.
Complete each step in the sequence given.
Table 2.1 Basic Setup Procedure
Step # Description
Action
Reference
1
Inspection
Visually inspect the power supply.
2
Installation
Install the power supply, ensuring
adequate ventilation.
3
Input Power
Connect AC input power.
4
Test
Perform functional tests for voltage
mode operation, current mode
operation, and front panel controls.
5
Select Wires
Select wires that can tolerate the DC
current output.
6
Connect Load
Connect the load wires to the DC output.
7
Connect Remote
Sensing (if required)
Connect remote sensing connectors on
power supply to load.
