Table 1.2 Rear Panel J1 Connector Terminals and Functions
Pin
Reference Name
Function
In/Output
J1-1
VPGM
Output Voltage
Programming Input
Input for voltage programming signals
from a voltage source (select S1-5 = ON
and:
S1-3 = OFF for 0-5 V range
S1-3 = ON for 0-10 V range
(see
for details)
Input
J1-2
IPGM
Output Current Limit
Programming Input
Input for current limit programming
signals from a voltage source (select
S1-6 = ON and:
S1-4 = OFF for 0-5 V range
S1-4 = ON for 0-10 V range
(see
for details)
Input
J1-3
RTN-P
1
1. Both RTN-PGM and RTN-MON are connected at the same potential.
Program Return
Return for voltage and current
programming signals
Input
J1-4
VMON
Output Voltage Monitor
Output for output voltage monitor signal
Output
J1-5
IMON
Output Current Monitor
Output for output current monitor signal
Output
J1-6
RTN-M
1
Monitor Return
Return for voltage and current monitoring
signals
Output
J1-7
N/C
No connection
None.
N/C
J1-8
GND-U
2
2. An isolated (see footnote below) supply voltage is available for external usage (e.g. remote on/off line). Its internal
impedance is approximately 100
Ω.
Return of 15 V User Signal
Return for 15 V isolated
3
supply voltage.
3. User supply is isolated to 600 V from the power supply output and chassis.
Output
J1-9
+15V-U
+ 15 V User Signal
+ 15 V isolated voltage supply
Output
J1-10
N/C
No connection
None.
N/C
J1-11
RTN-I
4
4. Safety Interlock circuit is isolated to 600 V from the power supply output and chassis.
Return Interlock
Return safety interlock (shutdown)
Input
J1-12
INT
Interlock Signal (4-15 V)
Safety interlock (shutdown) 4-15 V
Input
J1-13
N/C
No connection
None.
N/C
J1-14
RTN
Return Shutdown
Return master/slave S/D signal
Input
J1-15
S/D
Shutdown
Shutdown master/slave signal (5-15 V)
Input
