Configuration
Control Panel Parameters
6/30/06
105SL User Guide
11342L-001 Rev. A
Print Sensor Profile
A sensor profile shows sensor settings compared to actual sensor readings.
This label (which will extend across several actual labels or tags) can be
used to troubleshoot printing problems. To interpret the results of the
sensor profile, see
.
Figure 26 • Sensor Profile
To print a sensor profile:
1.
Press
PLUS (+)
to start this standard calibration procedure and print a
media sensor profile.
2.
If the sensitivity of the sensors must be adjusted, perform
Media and Ribbon Sensor Sensitivity on page 88
Table 9 • Printer Parameters (Page 9 of 19)
Parameter
Action/Explanation
SENSOR PROFILE
