Operations
Load Media in Peel-Off Mode
40
11342L-001 Rev. A
105SL User Guide
6/30/06
2.
Set the printer to Peel-Off mode. See
for instructions.
3.
Insert media into the printer. See
Insert Media into the Printer on page 31
for instructions.
4.
Open the printhead assembly by rotating the printhead open lever counterclockwise.
Peel option
a.
Remove the two thumb nuts that secure the front cover
bracket to the mounting screws on the inside of the front
panel.
b.
Remove the front cover bracket from the printer and store it.
If the printer has
the…
Then…
