Page 42
Operations
Load Media in Tear-Off Mode
34
11342L-001 Rev. A
105SL User Guide
6/30/06
Load Media in Tear-Off Mode
Tear-Off is the default mode.
shows roll media loaded in Tear-Off mode.
Figure 17 • Tear-Off Mode
To load media in Tear-Off mode, complete these steps:
1.
Set the printer to Tear-Off mode. See
for instructions.
2.
Insert media into the printer. See
Insert Media into the Printer on page 31
for instructions.
3.
Open the printhead assembly by rotating the printhead-open lever counterclockwise.
1
Printed label
2
Printhead-open lever
3
Outer media guide
4
Media supply hanger
5
Media supply guide
1
2
3
4
5
