6
ENGLISH
Technical Specification: Ducted Dc Inverter “YUHC” R-410A, 50Hz.
Model
Set YUHC18DUBAAR-K YUHC24DUBAAR-K YUHC36DUBACR-K YUHC48DUBACR-K YUHC60DSBACR-K
Indoor YUKC18DU-BAR-K YUKC24DU-BAR-K YUKC36DU-BCR-K YUKC48DU-BCR-K YUKC60DS-BCR-K
Outdoor YUJC18DU-BAR YUJC24DU-BAR YUJC36DU-BCR YUJC48DU-BCR YUJC60DS-BCR
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 380V~3~50Hz 380V~3~50Hz 380V~3~50Hz
Cooling
Capacity Btu/h 18,000 24,000 36,000 48,000 60,000
Input W 1,570 2,130 3,260 4,250 4,840
Rated current A 7 10 9 11 11
Heating
Capacity Btu/h 21,000 28,000 40,000 53,000 62,000
Input W 1,630 2,190 3,120 4,140 4,800
Rated current A 7 10 8 11 11
Max. input consumption W 2,600 2,800 3,560 4,750 5,950
Max. current A 10 11 10 13 16
Starting current A 1 1 1 1 1
Compressor
Type DC Inverter Rotary DC Inverter Scroll
Input W 1,650 1,650 3,665 3,665 3,665
Rated current (RLA) A 8 8 8 8 8
Locked rotor
Amp (LRA)
A 28 28 28 28 28
Protector Thermal
Capacitor µF 50 50 50 50 50
Refrigerant oil ml 480 480 500 500 500
Indoor fan motor
Type AC Motor
Input W 117 170 118 324 160
Capacitor µF 3 7 3 10 10
Speed (Hi/Me/Lo) r/min 900/800/690 1,100/1,020/900 820/695/620 870/770/700 870/770/700
Indoor coil
Number of rows 3 3 3 3 3
Fin spacing mm 2 2 2 2 2
Fin type Hydrophilic aluminium
Tube outside dia. mm Ø9.52
Material Type Innergroove tube
Coil length x
height x width
mm 800Ч254Ч66 800Ч254Ч66 1,150Ч254Ч66 1,150Ч254Ч66 1,150Ч305Ч66
Indoor air flow (Hi/Me/Lo) m 3 /h 1,020/870/700 1,275/1,170/1,030 2,070/1,950/1,860 2,400/2,300/2,200 2,800/2,700/2,600
Indoor external static pressure (Hi) Pa 40 40 70 70 96
Indoor noise level (Hi/Me/Lo) dB(A) 50/-/- 53/-/- 49/47/44 51/47/44 52/48/46
Indoor unit
Dimension
(WxHxD)
mm 1,095Ч805Ч290 1,095Ч805Ч290 1,350Ч298Ч800 1,350Ч320Ч800 1,350Ч320Ч800
Packing
(WxHxD)
mm 1,205Ч940Ч370 1,205Ч940Ч370 1,555Ч940Ч370 1,555Ч440Ч940 1,555Ч440Ч940
Net/Gross weight kg 38/45 38/45 48/57 70/80 70/80
Outdoor fan
motor
Input W 129 150 307 150Ч2 150Ч2
Capacitor µF 3 3 10 3.5Ч2 3.5Ч2
Speed r/min 770 800 740 800 800
Outdoor coil
Number of rows 2 2 1 1 1
Fin spacing mm 2 2 2 2 2
Fin type Hydrophilic aluminium
Tube outside dia. mm Ø9.52
Tube Material Innergroove tube
Coil length x
height x width
mm 630Ч660Ч44 620Ч813Ч44 955Ч915Ч22 715Ч610Ч22 1150Ч305Ч66
Outdoor air flow m 3 /h 2,400 3,000 5,000 6,000 6,000
Outdoor noise level dB(A) 56 55 57 58 58
Outdoor unit
Dimension
(WxHxD)
mm 840Ч677Ч310 894Ч860Ч302 990Ч960Ч340 940Ч1,245Ч340 940Ч1245Ч340
Packing
(WxHxD)
mm 965Ч770Ч395 1,043Ч915Ч395 1,120Ч1015Ч435 1,058Ч1300Ч435 1,058Ч1,300Ч435
Net/Gross weight kg 62.5/66.5 72/76.5 106/111 117/126 112/127
Refrigerant R-410A g 1,650 2,200 2,600 3,550 4,200
Throttle type EXV&Capillary
Refrigerant piping Liquid side/
Gas side
mm 6.35/12.7 9.53/16 9.53/16 9.53/16 9.53/16
