2-28 IMACS System Release 5.1.6 Server Cards
Model No. Running Head ACS-FRS Server Card Specifications FRS Card
4. Go to the Port Performance Monitoring Screen by pressing P from the FRS Main
Screen. Analyze the register and status information provided to help determine the
cause of the problem.
5. Go to the Circuits Screen of the FRS card (which can be accessed by selecting Circ
from the FRS Main Screen). Verify that the affected circuit STATUS is up (indicated
by a “U”). If it is not up, this may indicate that an LMI is down in the far end of the
circuit. Highlight the affected circuit and type P and the performance registers for the
circuit will appear. Analyze the information provided to help determine the cause of the
problem.
6. Loopbacks are available on the “C” ports only. If a “C” port with an LMI is looped back
toward itself, the PORT TYPE must be nni for the loopback to function.
7. If the FRS card is determined to be faulty, replace it and return the faulty unit for repair
to the location specified by your distributor.
2.6 ACS-FRS Server Card Specifications
ACS-FRS Card (Model 881160)
Input/Output Ports 68 logical ports (maximum)
Input Traffic Ports T1, E1, fT1, fE1, V.35, RS422, EIA530, OCU-DP, FRAD
Output Traffic ports T1, E1, fT1, fE1, V.35, RS422, EIA530
Output Port types UNI DCE, UNI DTE, NNI, Nx64K/56K FRAD
Max Frame Size 4K Bytes
Traffic Bandwidth 8 Mbps Full Duplex
Performance 4,000 Frames per second (maximum)
Number of PVCs 128
System Capacity Maximum 3 per System
Management RFC1315 DTE MIB, Frame Relay Service MIB, SNMP Alarm Traps
per RFC 1215
Connectivity SNMP or TELNET
LMI Options Q.933 Annex A, ANSI T1.617 Annex D, LMI (Gang of 4), None
Information Rates CIR = 0 to 2048 Kb/s, Bc = 0 to 2048 Kb, Be = 0 to 2048 Kb
Congestion Handling FECN, BECN
