IMACS System Release 5.1.6
Server Cards
Model No.
Running Head
Frame Relay Network
IPR Card
5.3.1.1
IPR to the Internet
The IPR card can be used as a gateway to the Internet through Frame Relay Network. Figure
5-2 shows how the IPR is routed through Frame Relay Network to the Internet Router.
Figure 5-2. IPR Card Routed to the Internet through Frame Relay Network
Frame Relay
Network
Internet
