Server Cards IMACS System Release 5.1.6 5-21
IPR Card IPR Card Configuration Screens and Settings
5.6.6 Frame Relay PVC Configuration Screen
The Frame Relay PVC Configuration screen, Figure 5-14, configures the Frame Relay PVC
by entering the PVC name, state, and port in which to activate.
Figure 5-14. IPR 10B2 and 10BT Frame Relay PVC Configuration Screen
Table 5-7. IPR 10B2 and 10BT Frame Relay PVC Configuration Screen Actions
Action Function
Refresh Refreshes the current screen
Add Adds a PVC
dElete Deletes a PVC
pgUp Scrolls up one page of information
pgDn Scrolls down one page of information
Status Displays the status of the current PVCs
Perf Displays the performance screen for the current PVC
Main Returns to the Frame Relay Menu screen
