Chapter 7 Basic Setting
ES-2048 User’s Guide
76
7.7 Port Setup
Use this screen to configure Switch port settings.Click Basic Setting > Port Setup in the
navigation panel to display the configuration screen.
Figure 28 Basic Setting > Port Setup
The following table describes the labels in this screen.
Index This field displays the index number of the rule. Click an index number to edit
the rule.
IP Address This field displays the IP address.
IP Subnet Mask This field displays the subnet mask.
VID This field displays the ID number of the VLAN group.
Default Gateway This field displays the IP address of the default gateway.
Manageable This field displays whether the Switch can be managed using the IP address.
Delete Check the management IP addresses that you want to remove in the Delete
column, then click the Delete button.
Cancel Click Cancel to clear the selected checkboxes in the Delete column.
Table 11 Basic Setting > IP Setup (continued)
LABEL DESCRIPTION
Table 12 Basic Setting > Port Setup
LABEL DESCRIPTION
Port This is the port index number.
* Settings in this row apply to all ports.
Use this row only if you want to make some settings the same for all ports. Use this
row first to set the common settings and then make adjustments on a port-by-port
basis.
Note: Changes in this row are copied to all the ports as soon as you
make them.
Active Select this check box to enable a port. The factory default for all ports is enabled. A
port must be enabled for data transmission to occur.
