Chapter 4 The Web Configurator
ES-2048 User’s Guide
51
General Setup
This link takes you to a screen where you can configure general identification
information about the Switch.
Switch Setup
This link takes you to a screen where you can set up global Switch parameters
such as VLAN type, MAC address learning, GARP and priority queues.
IP Setup
This link takes you to a screen where you can configure the IP address, subnet
mask (necessary for Switch management) and DNS (domain name server) and set
up IP management addresses.
Port Setup
This link takes you to a screen where you can configure settings for individual
Switch ports.
Advanced Application
VLAN
This link takes you to screens where you can configure port-based or 802.1Q
VLAN (depending on what you configured in the Switch Setup menu). You can also
configure subnet-based and protocol-based VLANs in these screens.
Static MAC
Forwarding
This link takes you to a screen where you can configure static MAC addresses for a
port. These static MAC addresses do not age out.
Filtering
This link takes you to a screen to set up filtering rules.
Spanning Tree
Protocol
This link takes you to screens where you can configure the RSTP or MSTP to
prevent network loops.
Bandwidth
Control
This link takes you to a screen where you can configure bandwidth limits on the
Switch.
Broadcast Storm
Control
This link takes you to a screen to set up broadcast filters.
Mirroring
This link takes you to screens where you can copy traffic from one port or ports to
another port in order that you can examine the traffic from the first port without
interference.
Link Aggregation This link takes you to a screen where you can logically aggregate physical links to
form one logical, higher-bandwidth link.
Port
Authentication
This link takes you to a screen where you can configure IEEE 802.1x port
authentication as well as MAC authentication for clients communicating via the
Switch.
Port Security
This link takes you to a screen where you can activate MAC address learning and
set the maximum number of MAC addresses to learn on a port.
Queuing Method This link takes you to a screen where you can configure queuing with associated
queue weights for each port.
Multicast
This link takes you to screens where you can configure various multicast features,
IGMP snooping and create multicast VLANs.
Auth and Acct
This link takes you to a screen where you can configure authentication and
accounting services via external servers. The external servers can be either
RADIUS (Remote Authentication Dial-In User Service) or TACACS+ (Terminal
Access Controller Access-Control System Plus).
IP Source Guard This link takes you to screens where you can configure filtering of unauthorized
DHCP and ARP packets in your network.
Loop Guard
This link takes you to a screen where you can configure protection against network
loops that occur on the edge of your network.
IP Application
Static Routing
This link takes you to a screen where you can configure static routes. A static route
defines how the Switch should forward traffic by configuring the TCP/IP parameters
manually.
Table 5 Navigation Panel Links (continued)
LINK
DESCRIPTION
