Basis Weight
(lb)
Grammage
Weight (gsm)
XeroxUncTextureLin24
(Xerox Uncoated Textured Linen 24 lb Bond) X 24 90 Uncoated N/A Plain 0 White 96 Yes Rough Simplex only recommended
ATA mode may help image quality.
XeroxUncTextureLin70
(Xerox Uncoated Texture Linen 70 lb Text) X 28 105 Uncoated N/A Plain 0 White 109 Yes Rough ATA mode may help image quality.
XeroxUncTextureLin80
(Xerox Uncoated Texture Linen 80 lb Cover) X 80 216 Uncoated N/A Plain 0 White 224 Yes Rough ATA mode may help image quality.
XeroxSupremeTextureCan
(Xerox Supreme Gloss Coated Texture Canvas 10 pt) X X 219 C1S (Coated
One Side) High-gloss Plain 0 White 264 Yes Smooth ATA mode may help image quality.
XeroxSupremeTextureLin
(Xerox Supreme Gloss Coated Texture Linen 10 pt) X X 219 C1S (Coated
One Side) High-gloss Plain 0 White 264 Yes Smooth ATA mode may help image quality.
XeroxSupremeTextureSilk
(Xerox Supreme Gloss Coated Texture Silk 10 pt) X X 219 C1S (Coated
One Side) High-gloss Plain 0 White 264 Yes Smooth ATA mode may help image quality.
XeroxClientCardL 2Up
(Xerox Client Card Lightweight 2 Up) X 80 118 C2S (Coated
Two Sides) Gloss Plain 0 White 170 No Smooth
If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in
the latest Customer Maintenance Manual Section 3.
Stack quality and stack height may be affected due to media structure or high area coverage.
For uniform image quality do not image within 5 mm of card edge.
Load and stack 50-100 sheets maximum due to media structure.
TAB may need to be cleaned prior to running media.
A DocuCard Enabler Kit is available to facilitate feeding and stacking of greater volumes.
XeroxClientCardH 2Up
(Xerox Client Card Heavyweight 2 Up) X 60 163 C2S (Coated
Two Sides) Gloss Plain 0 White 170 No Smooth
If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in
the latest Customer Maintenance Manual Section 3.
Stack quality and stack height may be affected due to media structure or high area coverage.
For uniform image quality do not image within 5 mm of card edge.
Load and stack 50-100 sheets maximum due to media structure.
TAB may need to be cleaned prior to running media.
A DocuCard Enabler Kit is available to facilitate feeding and stacking of greater volumes.
XeroxDocuGlossC 1up
(Xerox DocuGloss Card 1up) X X 60 163 Uncoated N/A Plain 0 White 170 No Regular
If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in
the latest Customer Maintenance Manual Section 3.
Stack quality and stack height may be affected due to media structure or high area coverage.
For uniform image quality do not image within 5 mm of card edge.
TAB may need to be cleaned prir to running media.
Load and stack 50-100 sheets maximum due to media structure.
A DocuCard Enabler Kit is available to facilitate feeding and stacking of greater volumes.
XeroxDocuGlossC 2up
(Xerox DocuGloss Card 2up) X X 60 163 Uncoated N/A Plain 0 White 170 No Regular
If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in
the latest Customer Maintenance Manual Section 3.
Stack quality and stack height may be affected due to media structure or high area coverage.
For uniform image quality do not image within 5 mm of card edge.
TAB may need to be cleaned prir to running media.
Load and stack 50-100 sheets maximum due to media structure.
A DocuCard Enabler Kit is available to facilitate feeding and stacking of greater volumes.
XeroxValuPeel C 1up
(Xerox Value Peel Card Coated 1 up) X X 80 216 C1S (Coated
One Side) Gloss Plain 0 White 170 No Smooth
For uniform image quality do not image within 5 mm of card edge.
Load and stack 50-100 sheets maximum due to media structure.
It is recommended to not image on back if laminated.
TAB may need to be cleaned prior to running media.
XeroxValuPeel C 2up
(Xerox ValuPeel Card Coated 2 up) X X 80 216 C1S (Coated
One Side) Gloss Plain 0 White 170 No Smooth
For uniform image quality do not image within 5 mm of card edge.
Load and stack 50-100 sheets maximum due to media structure.
It is recommended to not image on back if laminated.
TAB may need to be cleaned prior to running media.
XeroxValuPerf C 1up
(Xerox ValuPerfCard Coated 1up) X X 80 216 C1S (Coated
One Side) Gloss Plain 0 White 170 No Smooth
For uniform image quality do not image within 5 mm of card edge.
Load and stack 50-100 sheets maximum due to media structure.
It is recommended to not image on back if laminated.
TAB may need to be cleaned prior to running media.
XeroxValuPerf C 2up
(Xerox ValuPerfCard Coated 2 up) X X 80 216 C1S (Coated
One Side) Gloss Plain 0 White 170 No Smooth
For uniform image quality do not image within 5 mm of card edge.
Load and stack 50-100 sheets maximum due to media structure.
It is recommended to not image on back if laminated.
TAB may need to be cleaned prior to running media.
XeroxValuPeel U 1up
(Xerox ValuPeelCard Uncoated 1 up) X X 80 216 Uncoated N/A Plain 0 White 194 No Regular
For uniform image quality do not image within 5 mm of card edge.
Load and stack 50-100 sheets maximum due to media structure.
It is recommended to not image on back if laminated.
TAB may need to be cleaned prior to running media.
Xerox iGen4 90/110 Digital Production Press, Xerox iGen4 220 Perfecting Press, and iGen4 Xerox Automated Packaging Solution configuration North America Custom Media List February, 2011
The Xerox CUSTOM Media List contains custom media that has been tested on the Xerox iGen4 90/110 Digital Production Press for image quality and performance.
Custom media on this list are digitally optimized, designed and manufactured for performance in Xerox digital printing equipment.
Best Practices for Operation are outlined below.
Customers should validate the Best Practices for Operation are acceptable for their application.
*Any alterations to the product's basic design, including sheet size, must be tested and approved by the Xerox Media & Compatibles Technology Center.*
When purchasing a particular media product for the first time, customers are advised to purchase small quantities to insure that expectations are met.
CUSTOM media may be ordered through the Xerox Supply Account Manager.
Stock Library Name (Full Media Name)
It is imperative to utilize the bolded, abbreviated stock name for easy
migration to future enhancements to the stock library and media
management tools.
Base Size Tested
Best Practices for Operation
8.5 x 11 8.5 x 14 17 x 11 18 x 12 Other Size
Weight of 500
sheets of the
paper specific
to grade type
Weight of the
paper in grams
per square
meter
Sides Coated Coating Type Cleanup Finish Type Sequence Color Thickness
(microns)
Textured
Cards
