Product Description Weight g/m 2 Coating type Size Application Number of
sheets run Image
Quality
Permanence
Runnability Auto
Duplex
Date of
test
Notes Xerox Guaranteed Media
Alternative
Green - Good test results, purchase a small quantity to insure expectations are met.
Yellow - Customer should validate the limitations are acceptable for their application. Potential for increased service.
Not Recommended
Xerox iGen4 90/110 Digital Production Press, Xerox iGen4 220 Perfecting Press, and iGen4 Xerox Automated Packaging Solution configuration North America Tested Media List February, 2011
The Non-Xerox Tested Media List contains non-Xerox branded paper and specialty media. Xerox has tested many media products on the Xerox iGen4 90/110 Digital Production Press and based on such testing have published this list of tested media products which may or may not, at the time of and based upon such testing, meet Xerox performance criteria. No subsequent
testing has been done and therefore no determination can be made as to whether or not such products would currently fail or pass Xerox performance criteria.
Xerox makes no guarantees or warranties, either expressed or implied, concerning the performance, use, consistency or replacement of non-Xerox branded media or throughput products. Customers should inquire directly of their paper distributor or manufacturer for any guarantees they may offer. When purchasing a
particular media product for the first time, customers are advised to purchase small quantities to insure that expectations are met. For guaranteed best performance, use digitally optimized paper and specialty media from Xerox Supplies.
Anthem Gloss 80# Text 118 Coated 2 side - Gloss 12x18 2000 Yes Mar-04
Aug -05
Image mottle was image quality artifact
EIP mode may be needed for acceptable image permanence.
POTENTIAL SERVICE RISK
Xerox Digital Color Elite Gloss 80lb Text
Camelot 80 lb Gloss Text 118 Coated 2 side - Gloss 12.5x19 1000 Yes Nov-05 Deletions and wrinkles were evident on the prints generated Xerox Digital Color Elite Gloss 80lb Text
Corniche Gloss 80 lb Text 118 Coated 2 Side Gloss 14.3x19 Yes Oct-03
Multiple jams
POTENTIAL SERVICE RISK Xerox Digital Color Elite Gloss 80lb Text
Gusto 80 lb Gloss Text 118 Coated 2 side - Gloss 14.33x19.25 2000 Yes Apr-04 POTENTIAL SERVICE RISK Xerox Digital Color Elite Gloss 80lb Text
Hanno 80 lb Gloss Text 118 Gloss 8.5x11 &
11x17 500 Yes Jun-04 Multifeeds may be attributable to poor cut quality - media run from another lot ran without
jamming Xerox Digital Color Elite Gloss 80lb Text
Hannoart 80 lb Gloss Text 118 Coated 2 side - Gloss 14.33x19.25 2000 Yes Xerox Digital Color Elite Gloss 80lb Text
Mac 80 lb Gloss Text 118 Coated 2 side - Gloss 14.33x19.25 2000 Yes Xerox Digital Color Elite Gloss 80lb Text
Northwest Gloss 80 lb Text 118 Coated 2 side - Gloss 18 x 12 2000 Yes Aug-02 Mottle is image quality artifact Xerox Digital Color Elite Gloss 80lb Text
Opus 80# Text Gloss 118 Coated 2 side - Gloss 18 x 12 500 Yes Apr-05 Xerox Digital Color Elite Gloss 80lb Text
Potlatch McCoy Gloss 80 lb. Text 118 Coated 2 side - Gloss -
Smooth Multiple 5000 Yes Jul-04 Xerox Digital Color Elite Gloss 80lb Text
Productolith 80 lb Gloss Text 118 Coated 2 side - Gloss 12.375 x
18.125
2000 Yes Sep-04
POTENTIAL SERVICE RISK
Slight mottle
EIP mode may be needed for acceptable image permanence.
Xerox Digital Color Elite Gloss 80lb Text
Sappi LustroGloss 80T
(Sappi LustroGloss 80 lb. Text)
118 Coated 2 side - Gloss -
Smooth
Multiple 5000 Yes Jan-04 Xerox Digital Color Elite Gloss 80lb Text
Stirling Gloss Text 118 C2S 12 x 18 300 Yes Nov-08 Xerox Digital Color Elite Gloss
Sterling Ultra 80 lb. Gloss Text 118 Coated 2 side - Gloss 12 x 18 2000 Yes Apr-05 Mottle is image quality artifact Xerox Digital Color Elite Gloss 80lb Text
Asia Pulp & Paper 80 lb Text 120 Coated 2 side - Gloss 18 x 12 1300 Yes Jun-05 Mottle is image quailty artifact. Xerox Digital Color Elite Gloss 80lb Text
Esse Pearlized Silver 80# Text 120 C2S 12x18 100 Yes Feb-06 Xerox Digital Color Elite Gloss 80lb Text
Futura Laser 120 C2S - gloss 18 x 12 250 No Sep-09 Digital Color Select Gloss 80lb text
Jefferson 80# Gloss Text 120 Coated 2 side Gloss 11 x 17 924 Yes Oct-10 Xerox Digital Color Elite Gloss
Not Recommended
