Xerox 110 - Manual (Page 2)

Basis Weight
(lb)
Grammage
Weight (gsm)
Xerographic
Bond
XeroxCXSel24B3HD
(Xerox Color Xpressions Select 24 lb. 3Hole Drilled)
3 Hole
Drilled 003R11541 24 90 Uncoated N/A Plain 0 White 103 No Regular Stack quality and stack height may be affected due to media structure or high area coverage.
XeroxCXSel24B
(Xerox Color Xpressions Select 24 lb.) 003R11540 003R11542 003R11543 24 90 Uncoated N/A Plain 0 White 96 Yes Regular
XeroxCXElite28B3HD
(Xerox Color Xpressions Elite 28 lb 3 Hole Drilled)
3 Hole
Drilled 3R11761 28 105 Uncoated N/A Plain 0 White 109 Yes Regular
If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in
the latest Customer Maintenance Manual Section 3.
Stack quality and stack height may be affected due to media structure or high area coverage
XeroxCXElite28B
(Xerox Color Xpressions Elite 28 lb.) 3R11760 3R11762 3R11763 3R11777 28 105 Uncoated N/A Plain 0 White 109 Yes Regular If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in
the latest Customer Maintenance Manual Section 3.
XeroxCXPlanet20_28B
(Xerox ColorXpresssions Planet 20 28 lb.) 3R11800 3R11801 3R11802 28 105 Uncoated N/A Plain 0 White 103 Yes Regular
XeroxPlanet30CW28B
(Xerox Planet 30 Cream White 28 lb.) 3R11820 3R11821 3R11822 28 105 Uncoated N/A Plain 0 White 112 Yes Regular
If image permanence adjustment is required, refer to ADJ 1 - Pressure Roll Contact Arc Adjustment procedure in
the latest Customer Maintenance Manual.
This media may have a mottled appearance due to paper formation (image density and gloss).
XeroxPlanet30WW28B
(Xerox Planet 30 Warm White 28 lb.) 3R11823 3R11824 28 105 Uncoated N/A Plain 0 White 112 Yes Regular
If image permanence adjustment is required, refer to ADJ 1 - Pressure Roll Contact Arc Adjustment procedure in
the latest Customer Maintenance Manual.
This media may have a mottled appearance due to paper formation (image density and gloss).
XeroxCXPlanet100_28B
(Xerox ColorXpresssions Planet 100 28 lb.) 3R11815 28 105 Uncoated N/A Plain 0 White 112 Yes Regular Optimization of decurler settings may be needed for best stacking and runnability.
XeroxCXElite32B
(Xerox Color Xpressions Elite 32 lb.) 3R11764 3R11765 3R11766 32 120 Uncoated N/A Plain 0 White 128 Yes Regular If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in
the latest Customer Maintenance Manual Section 3.
Cover weight
XeroxCXElite60C
(Xerox Color Xpressions Elite 60 lb. Cover) 3R11767 3R11768 3R11769 60 163 Uncoated N/A Plain 0 White 170 Yes Regular
If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in
the latest Customer Maintenance Manual Section 3.
XeroxCXPlanet20_65C
(Xerox ColorXpressions Planet 20 65 lb. Cover) 3R11803 3R11804 3R11805 65 176 Uncoated N/A Plain 0 White 176 Yes Regular
If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in
the latest Customer Maintenance Manual Section 3.
XeroxCXElite80C
(Xerox Color Xpressions + 80 lb. Cover) 3R11770 3R11771 3R11772 3R11773 80 216 Uncoated N/A Plain 0 White 224 Yes Regular
If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in
the latest Customer Maintenance Manual Section 3.
XeroxCXPlanet20_80C
(Xerox Color Xpressions Planet 20 80 lb. Cover) 3R11806 3R11807 3R11808 80 216 Uncoated N/A Plain 0 White 223 Yes Regular
XeroxPlanet30CW80C
(Xerox Planet 30 Cream White 80 lb. Cover) 3R11826 3R11827 3R11828 80 216 Uncoated N/A Plain 0 White 241 Yes Regular
If image permanence adjustment is required, refer to ADJ 1 - Pressure Roll Contact Arc Adjustment procedure in
the latest Customer Maintenance Manual.
This media may have a mottled appearance due to paper formation (image density and gloss).
Score for optimal folding performance.
XeroxPlanet30WW80C
(Xerox Planet 30 Warm White 80 lb. Cover) 3R11829 3R11830 3R11831 80 216 Uncoated N/A Plain 0 White 241 Yes Regular
If image permanence adjustment is required, refer to ADJ 1 - Pressure Roll Contact Arc Adjustment procedure in
the latest Customer Maintenance Manual.
This media may have a mottled appearance due to paper formation (image density and gloss).
Score for optimal folding performance.
XeroxCXElite100C
(Xerox Color Xpressions Elite 100 lb. Cover) 3R11774 3R11775 3R11776 100 270 Uncoated N/A Plain 0 White 273 Yes Regular
XeroxCXPlanet20_100C
(Xerox Color Xpressions Planet 20 100 lb. Cover) 3R11809 3R11810 3R11811 100 270 Uncoated N/A Plain 0 White 322 Yes Regular If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in
the latest Customer Maintenance Manual Section 3.
The Xerox Guaranteed Media List contains Xerox paper and specialty media that has been extensively tested on the Xerox iGen4 90/110 Digital Production Press for image quality and performance. All Xerox paper and specialty media on this list are digitally optimized, designed and
manufactured for optimal performance in Xerox digital printing equipment. Our extensive testing and stringent specifications ensure that we are able to guarantee the performance and consistency of Xerox paper and specialty media. Xerox paper and specialty media are tested and qualified
by Xerox laboratories to guarantee consistent quality.
Stock Library Name (Full Media Name)
It is imperative to utilize the bolded, abbreviated stock name for easy
migration to future enhancements to the stock library and media
management tools.
Xerox iGen4 90/110 Digital Production Press, Xerox iGen4 220 Perfecting Press, and iGen4 Xerox Automated Packaging Solution configuration North America Guaranteed Media List February, 2011
Uncoated Cover Stocks
Finish
Uncoated Business Papers
(Bond, xerographic and laser grades)
Sequence Thickness
(microns)
Weight of the
paper in grams
per square
meter
Sides Coated Coating Type Type
Standard cut sizes
Best Practices for Operation
8.5 x 11 8.5 x 14 17 x 11 18 x 12 Other Size
Weight of 500
sheets of the
paper specific
to grade type
Color Cleanup
