York 12 SEER H*RC018 THRU 060 - Manual (Page 10)

036-21137-004 Rev. C (0505)
10 Unitary Products Group
COOLING CAPACITY - With Variable Speed Furnaces
UNIT MODEL
VARIABLE SPEED
FURNACE MODEL
COIL MODEL 1 W
COOLING
RATED
CFM
NET MBH SEER
W/O TXV
SEER
+ TXV 2
EER
TOTAL SENS.
1 PH 12 SEER AC - VARIABLE SPEED 3
H2RC018S06
P1DUA12V/PV8A12****UH G1FA024S14 14 600 19.6 13.4 – 13.00 12.55
P1DUA12V/PV8A12****UH G2FD024(S,H)14 14 600 20.0 13.6 – 14.00 12.90
P1XDB12V G2FD024(S,H)17 17 620 20.2 14.0 – 13.75 12.90
P1XUB12V G1FA024S17 17 620 19.6 13.4 – 13.00 12.45
P1XUB12V G2FD024(S,H)17 17 620 20.0 13.6 – 13.75 12.80
H2RC024S06
P1DUA12V/PV8A12****UH G1FA024S14 14 750 23.4 16.8 – 13.00 11.60
P1DUA12V/PV8A12****UH G2FD024(S,H)14 14 750 24.0 17.3 – 13.00 12.05
P1XDB12V G2FD024(S,H)17 17 815 24.2 17.5 – 12.50 11.85
P1XUB12V G1FA024S17 17 730 23.6 17.0 – 13.00 11.80
P1XUB12V G2FD024(S,H)17 17 730 24.2 17.5 – 13.00 12.10
H2RC030S06
P1DUA12V/PV8A12****UH G1FA030S14 14 975 29.6 21.1 – 12.50 11.55
P1DUA12V/PV8A12****UH G2FD035(S,H)14 14 975 30.4 21.7 – 13.00 11.80
P1DUB16V/PV8B16****UH G1FA036S17 17 1050 30.6 21.9 – 13.00 11.95
P1DUB16V/PV8B16****UH G2FD030(S,H)17 17 1050 30.6 21.9 – 13.00 11.95
P1XDB12V G2FD030(S,H)17 17 1050 30.6 21.9 – 12.50 11.60
P1XUB12V G1FA036S17 17 1020 30.4 21.7 – 12.75 11.70
P1XUB12V G2FD030(S,H)17 17 1020 30.4 21.7 – 12.75 11.70
P1XUC16V G1FA036S21 21 1000 30.6 21.9 – 13.00 12.00
P1XUC16V G2FD036(S,H)21 21 1000 31.4 22.5 – 13.00 12.30
H2RC036S06
P1DUA12V/PV8A12****UH G1FA036S14 14 1185 33.8 23.6 – 12.00 10.95
P1DUA12V/PV8A12****UH G2FD035(S,H)14 14 1185 33.2 23.2 – 11.50 10.80
P1DUB16V G1FA036S17 17 1200 33.4 23.4 – 12.00 11.15
P1DUB16V G2FD036(S,H)17 17 1200 34.4 24.2 – 12.25 11.40
P1DUC20V/PV8C20****UH G1FA036S21 21 1200 33.6 23.6 – 12.00 11.30
P1DUC20V/PV8C20****UH G2FD036(S,H)21 21 1200 34.8 24.4 – 13.00 11.60
P1XDB12V G2FD036(S,H)17 17 1130 34.4 24.4 – 12.00 11.15
P1XUB12V G1FA036S17 17 1220 33.2 23.2 – 11.50 10.80
P1XUB12V G2FD036(S,H)17 17 1200 34.0 23.8 – 12.00 11.05
P1XUC16V G1FA036S21 21 1200 33.4 23.4 – 12.00 11.15
P1XUC16V G2FD036(S,H)21 21 1200 34.8 24.4 – 12.75 11.45
P1XUC20V G1FA048S21 21 1200 34.6 25.8 – 13.00 11.60
P1XUC20V G2FD042(S,H)21 21 1200 35.2 24.7 – 13.00 11.65
P1XUD20V G2FD048(S,H)24 24 1260 36.4 25.5 – 12.75 11.65
H1RC036S(25,46)
P1DUA12V/PV8A12****UH G1FA036S14 14 1185 33.6 25.2 – 12.00 11.05
P1DUA12V/PV8A12****UH G2FD035(S,H)14 14 1185 33.0 24.5 – 12.00 10.90
P1DUB16V/PV8B16****UH G1FA036S17 17 1250 33.4 24.8 – 12.00 11.15
P1DUB16V G2FD036(S,H)17 17 1250 34.0 25.3 – 12.50 11.30
P1DUC20V/PV8C20****UH G1FA036S21 21 1200 33.6 25.0 – 12.25 11.45
P1DUC20V/PV8C20****UH G2FD036(S,H)21 21 1200 34.8 25.9 – 13.00 11.75
P1XUB12V G1FA036S17 17 1220 33.2 24.6 – 12.00 10.95
P1XUB12V G2FD036(S,H)17 17 1200 34.0 25.3 – 12.25 11.10
P1XUC16V G1FA036S21 21 1260 33.4 24.8 – 12.00 11.15
P1XUC16V G2FD036(S,H)21 21 1200 34.8 25.9 – 12.75 11.60
P1XUC20V G1FA048S21 21 1260 35.6 26.5 – 13.00 11.50
P1XUC20V G2FD042(S,H)21 21 1260 35.0 26.1 – 12.75 11.65
P1XUD20V G2FD048(S,H)24 24 1260 35.8 26.6 – 13.00 11.85
H2RC042S06
P1DUB16V/PV8B16****UH G1FA048S17 17 1400 42.5 30.7 – 12.50 11.05
P1DUC20V/PV8C20****UH G1FA048S21 21 1400 42.0 30.2 – 12.50 11.15
P1XDD20V G2FD048(S,H)24 24 1365 43.0 31.1 – 12.80 11.35
P1XUC16V G1FA048S21 21 1400 42.0 30.2 – 12.50 11.10
P1XUD20V G1FA060S24 24 1430 43.5 31.2 – 13.00 11.35
P1XUD20V G2FD048(S,H)24 24 1430 43.0 31.1 – 12.25 11.05
For Notes See Page 11.
