246723-YTG-J-1006
Unitary Products Group 15
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
OUTDOOR UNIT MODEL NO. CZB04211
INDOOR COIL MODEL NO. G2FD048S21
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1200 1400 1600
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 36.0 38.4 36.8 40.5 45.9 38.2 39.0 38.3 41.8 46.9 40.3 39.5 39.7 43.2 47.9
S.C. 35.9 34.7 29.1 28.6 22.1 38.1 37.8 31.5 30.8 23.4 40.3 40.9 33.9 33.1 24.8
K.W. 3.3 3.3 3.3 3.3 3.4 3.3 3.3 3.3 3.3 3.4 3.3 3.3 3.3 3.3 3.4
75
T.C. 38.9 40.1 40.9 43.9 49.3 40.7 41.2 42.0 45.3 50.7 42.6 42.3 43.1 46.8 52.0
S.C. 38.9 34.9 30.1 29.4 23.4 40.8 37.8 32.5 31.7 24.8 42.6 40.8 34.9 34.1 26.3
K.W. 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9
85
T.C. 37.5 39.3 38.9 42.2 47.6 39.5 40.1 40.1 43.6 48.8 41.4 40.9 41.4 45.0 49.9
S.C. 37.4 34.8 29.6 29.0 22.8 39.4 37.8 32.0 31.3 24.1 41.4 40.8 34.4 33.6 25.5
K.W. 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1
95
T.C. 35.5 37.0 36.7 39.9 44.8 37.2 37.9 37.7 41.0 45.8 39.0 38.8 38.8 42.1 46.8
S.C. 35.4 33.6 28.6 27.9 21.8 37.2 36.3 30.9 30.2 23.2 38.9 38.9 33.2 32.5 24.5
K.W. 3.6 3.6 3.6 3.6 3.7 3.6 3.6 3.6 3.6 3.7 3.6 3.6 3.6 3.6 3.7
105
T.C. 33.5 34.7 34.5 37.5 42.0 35.0 35.7 35.3 38.4 42.8 36.5 36.7 36.2 39.3 43.6
S.C. 33.4 32.5 27.5 26.9 20.8 34.9 34.8 29.7 29.1 22.2 36.5 37.1 31.9 31.3 23.6
K.W. 4.1 4.1 4.1 4.2 4.2 4.1 4.1 4.1 4.2 4.2 4.1 4.1 4.1 4.2 4.2
115
T.C. 31.6 32.5 32.3 35.3 39.2 32.9 33.6 33.0 35.9 39.9 34.2 34.7 33.7 36.6 40.5
S.C. 31.5 31.3 26.5 25.9 19.9 32.8 33.3 28.6 28.1 21.2 34.0 35.3 30.7 30.3 22.6
K.W. 4.6 4.6 4.6 4.7 4.7 4.6 4.6 4.6 4.7 4.7 4.7 4.7 4.6 4.7 4.7
125
T.C. 29.7 30.3 30.2 33.0 36.5 30.7 31.8 30.7 33.4 37.0 31.8 32.7 31.2 33.8 37.5
S.C. 29.6 30.2 25.5 24.8 18.9 30.6 31.8 27.5 27.0 20.3 31.6 33.5 29.5 29.2 21.7
K.W. 5.2 5.1 5.2 5.2 5.2 5.2 5.2 5.2 5.2 5.2 5.2 5.2 5.2 5.2 5.2
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
MA16C FC/MC48C 1.00 1.00 1.00
MA14D FC/MC48D 1.00 1.00 1.00
MA14D G*FD060H24 1.01 1.00 1.00
MV16C MC48C 1.01 1.00 1.00
MV20D MC48D 1.01 1.00 1.00
AHP/SHP48 – 1.01 1.00 1.00
AHP/SHP60 – 1.01 1.00 1.00
AV/SV48 – 1.01 1.00 0.95
F*FP045 – 1.00 1.00 1.00
F*FP048 – 1.00 1.00 1.00
– FC/MC/PC/UC48 1.00 1.00 1.00
– G*FA060S21,24 1.01 1.00 1.00
– G*FD060H24 1.01 1.00 1.00
– HC60 0.98 0.98 1.00
– HD60 0.97 0.97 1.00
Variable Speed
Furnace
Coil T.C. S.C. KW
PV8*C16 FC/MC/PC48C 1.00 1.00 1.00
PV8*C20 FC/MC/PC48C 1.00 1.00 1.00
PV9*C16 FC/MC/PC48C 1.00 1.00 1.00
PV9*C20 FC/MC/PC48C 1.00 1.00 1.00
PV9*D20 FC/MC/PC48D 1.00 1.00 1.00
PV8*C20 HC60 0.98 0.98 1.00
PV9*C20 HC60 0.98 0.98 1.00
PV8*C16 HD60 0.98 0.98 1.00
PV8*C20 HD60 0.98 0.98 1.00
PV9*C16 HD60 0.98 0.98 1.00
PV9*C20 HD60 0.98 0.98 1.00
PV9*D20 HD60 0.98 0.98 1.00
