York H4TS024 - Manual (Page 5)

036-21023-005 Rev. A (0802)
Unitary Products Group 5
H4TS036
P1XUB12V055
P1DUB16V080 17
17
G1UA048S17
1 750 20.0 16.0
14.5
13.4
2 1150 34.8 26.0 11.0
G1FA048S17
1 750 20.0 16.0
14.5
13.4
2 1150 34.8 26.0 11.0
G2FD036S17
1 750 20.0 16.0
14.5
13.4
2 1150 34.8 26.0 11.0
G2FD046S17
1 750 20.0 16.0
14.5
13.4
2 1150 34.8 26.0 11.0
P1XUC16V075 21
G1UA048S21
1 770 21.0 16.6
15.0
14.1
2 1185 36.8 27.0 11.6
G1FA048S21
1 770 21.0 16.6
15.0
14.1
2 1185 36.8 27.0 11.6
G2FD036S21
1 770 20.4 16.0
15.0
13.6
2 1185 35.4 26.0 11.4
G2FD042S21
1 770 20.4 16.0
15.0
13.6
2 1185 35.4 26.0 11.4
G2FD048S21
1 770 21.0 16.6
15.5
14.1
2 1185 36.8 27.0 11.6
P1XUC20V095
P1DUC20V096
21
G1UA048S21
1 770 21.0 16.0
15.5
14.3
2 1200 37.0 27.0 11.6
G1FA048S21
1 770 21.0 16.0
15.5
14.3
2 1200 37.0 27.0 11.6
G2FD036S21
1 770 20.4 16.4
15.0
13.7
2 1200 35.4 26.0 11.4
G2FD042S21
1 770 20.4 16.4
15.0
13.7
2 1200 35.4 26.0 11.4
G2FD048S21
1 770 21.0 16.6
15.5
14.2
2 1200 37.0 27.0 11.6
P1XUD20V112 24 G2FD048S24
1 770 21.0 16.6
15.5
14.2
2 1200 37.0 27.0 11.6
H4TS048
P1XUC16V075
P1XUC20V095
P1DUC20V096
21
G1UA048S21
1 1050 24.0 19.0
14.5
13.5
2 1500 47.5 35.0 10.2
G1FA048S21
1 1050 24.0 19.0
14.5
13.5
2 1500 47.5 35.0 10.2
G1UA060S21
1 1050 25.0 20.0
14.7
13.3
2 1500 49.0 36.0 10.4
G1FA060S21
1 1050 25.0 20.0
14.7
13.3
2 1500 49.0 36.0 10.4
G2FD048S21
1 1050 24.0 19.0
14.7
13.9
2 1500 47.5 35.0 10.2
P1XUD20V112 24
G1UA060S24
1 1050 25.2 20.2
15.0
13.8
2 1500 49.5 36.5 10.5
G1FA060S24
1 1050 25.2 20.2
15.0
13.8
2 1500 49.5 36.5 10.5
G2FD048S24
1 1050 24.0 19.0
14.8
14.0
2 1500 47.5 35.0 10.3
G2FD060S24
1 1050 25.2 20.2
15.0
13.8
2 1500 49.5 37.5 10.5
H4TS060
P1XUC20V095
P1DUC20V096
21
G1UA060S21
1 1250 33.0 26.4
13.7
12.6
2 1900 59.0 43.0 10.0
G1FA060S21
1 1250 33.0 26.4
13.7
12.6
2 1900 59.0 43.0 10.0
P1XUD20V112 24
G1UA060S24
1 1250 33.0 26.4
14.0
13.1
2 1900 59.0 43.0 10.4
G1FA060S24
1 1250 33.0 26.4
14.0
13.1
2 1900 59.0 43.0 10.4
G2FD060S24
1 1250 33.0 26.4
14.0
13.1
2 1900 59.0 43.0 10.4
G2FD061H24
1 1250 34.0 27.0
14.3
13.1
2 1900 60.0 44.0 10.6
COOLING CAPACITY - Variable Speed Furnace (Continued)
UNIT
MODEL
VARIABLE SPEED
FURNACE MODEL
W COIL MODEL
COOLING
STAGE
(# CYL)
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
