3-22
3.3.3 Adjusting the weight supports under the UW/W 100
Parts and Tools needed
No. Description Quantity
1 Hexagon wrench 3 mm 1
3.3.3.1 Location of the weight supports on a 65” printer
There are 2 weight supports on the UW/W 100 system for a 65” machine, see the images below for their
positions.
FRONT VIEW
No Description
1 Weight support
3.3.3.2 Location of the weight supports on a 90” printer
There are 4 weight supports on the UW/W 100 system for a 90” machine, see the images below for their
positions.
FRONT VIEW
No Description
1 Weight support
