Xantrex Technology PV100S-480 - Manual (Page 44)

Planning
2–10 152315 Rev C
Figure 2-6 AC Interface Enclosure Conduit Entry, Left Side
Figure 2-7 DC Interface Enclosure, Bottom Side
Figure 2-8 Communications Enclosure Conduit Entry, Bottom Side
8"
(20 cm)
AC Disconnect Switch (S1)
8" (20 cm)
1" (2.5 cm)
5" (13 cm)
Backside of
Transformer
Enclosure
(partial view)
8"
8"
2"
2"
8"
(20 cm)
8" (20 cm)
2" (5 cm)
2" (5 cm)
10 ½"
1"
3"
1"
1" (2.5 cm)
1" (2.5 cm)
10.5" (27 cm)
3" (8 cm)
