York PREDATOR 90 - Manual (Page 17)

246646-YTG-C-0606
Unitary Products Group 17
TABLE 9: COOLING CAPACITY DH150 (12-1/2 TON) UNIT
Air On
Evap. Coil
Temperature of Air on Condenser Coil 85°F Temperature of Air on Condenser Coil 95°F
CFM
WB
(°F)
Tot.
Cap. *
(MBH)
Tot.
Input †
(kW)
Sensible Capacity (MBH) *
Return Dry Bulb (°F)
Tot.
Cap. *
(MBH)
Tot.
Input †
(kW)
Sensible Capacity (MBH) *
Return Dry Bulb (°F)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
3750
72 165 11.9 95 85 74 63 52 - - 159 13.1 94 83 72 62 51 - -
67 158 11.8 124 114 103 92 82 71 60 151 13.0 121 111 100 89 79 68 57
62 148 11.6 147 137 126 115 105 94 83 141 12.8 141 135 124 113 103 92 81
57 138 11.5 138 135 124 113 103 92 81 132 12.8 132 130 120 109 98 87 77
4375
72 169 11.9 105 92 80 67 54 - - 163 13.2 103 91 78 65 53 - -
67 161 11.8 136 124 111 98 86 73 61 155 13.1 133 121 108 95 83 70 57
62 151 11.7 151 146 136 123 111 98 85 144 12.9 144 141 134 121 109 96 83
57 141 11.5 141 139 134 121 109 96 83 135 12.8 135 134 129 116 104 91 78
5000
72 172 12.0 115 100 86 71 56 - - 167 13.2 113 98 84 69 55 - -
67 165 11.9 148 134 119 105 90 76 61 159 13.1 145 131 116 101 87 72 58
62 155 11.7 155 155 146 132 117 102 88 148 12.9 148 148 144 129 115 100 85
57 144 11.6 144 144 144 129 115 100 86 139 12.9 139 139 139 124 109 95 80
5625
72 172 11.9 121 105 88 71 55 - - 166 13.2 120 104 87 70 54 - -
67 164 11.8 156 139 122 106 89 73 56 158 13.1 151 137 120 104 87 71 54
62 154 11.7 154 154 150 133 117 100 83 147 12.9 147 147 145 128 112 95 78
57 143 11.5 143 143 143 127 110 94 77 138 12.8 138 138 138 121 104 88 71
6250
72 171 11.9 127 109 90 72 53 - - 165 13.2 127 109 90 71 53 - -
67 164 11.8 163 144 126 107 88 70 51 157 13.1 157 143 125 106 88 69 50
62 154 11.6 154 154 154 135 116 98 79 146 12.9 146 146 146 127 108 90 71
57 143 11.5 143 143 143 124 106 87 68 137 12.8 137 137 137 118 99 81 62
Temperature of Air on Condenser Coil 105°F Temperature of Air on Condenser Coil 115°F
3750
72 152 14.6 91 80 70 59 48 - - 145 16.2 88 78 67 56 46 - -
67 143 14.5 118 107 97 86 75 64 54 135 15.9 114 104 93 82 72 61 50
62 133 14.3 133 128 118 107 96 86 75 125 15.8 125 122 111 101 90 79 68
57 124 14.2 124 122 111 100 90 79 68 116 15.7 116 113 103 92 81 71 60
4375
72 156 14.7 101 88 76 63 50 - - 149 16.2 99 86 73 61 48 - -
67 147 14.5 130 118 105 92 80 67 54 138 15.9 127 114 102 89 77 64 51
62 137 14.3 137 134 128 115 103 90 77 129 15.8 129 127 122 109 96 84 71
57 127 14.3 127 126 121 108 95 83 70 119 15.7 119 118 112 100 87 75 62
5000
72 160 14.7 111 96 82 67 53 - - 153 16.2 109 94 80 65 50 - -
67 150 14.5 142 128 113 99 84 70 55 142 15.9 140 125 111 96 81 67 52
62 140 14.4 140 140 138 123 109 94 80 132 15.8 132 132 132 118 103 88 74
57 130 14.3 130 130 130 116 101 87 72 122 15.8 122 122 122 108 93 78 64
5625
72 159 14.7 118 102 85 68 52 - - 152 16.2 116 100 83 66 50 - -
67 149 14.5 145 134 118 101 85 68 51 141 15.9 140 132 115 99 82 66 49
62 139 14.4 139 139 138 121 105 88 72 131 15.8 131 131 131 115 98 81 65
57 129 14.3 129 129 129 113 96 80 63 121 15.8 121 121 121 105 88 71 55
6250
72 158 14.7 126 107 88 70 51 - - 151 16.2 124 105 87 68 49 - -
67 148 14.5 148 141 122 104 85 67 48 140 15.9 140 139 120 102 83 64 46
62 138 14.3 138 138 138 119 101 82 63 130 15.8 130 130 130 112 93 74 56
57 128 14.3 128 128 128 110 91 72 54 120 15.8 120 120 120 102 83 64 46
Temperature of Air on Condenser Coil 125°F
3750
72 138 17.7 86 75 64 54 43 - -
67 126 17.3 111 100 90 79 68 58 47
62 118 17.2 118 116 105 94 83 73 62
57 108 17.2 108 105 94 84 73 62 52
4375
72 142 17.7 96 84 71 58 46 - -
67 130 17.3 124 111 99 86 73 61 48
62 121 17.2 121 120 116 103 90 78 65
57 111 17.2 111 109 104 91 79 66 54
5000
72 146 17.7 107 92 78 63 48 - -
67 133 17.4 133 122 108 93 79 64 50
62 124 17.2 124 124 124 112 97 83 68
57 114 17.2 114 114 114 99 85 70 56
5625
72 145 17.7 114 98 81 65 48 - -
67 132 17.4 132 130 113 96 80 63 46
62 123 17.3 123 123 123 108 91 75 58
57 113 17.2 113 113 113 96 80 63 47
6250
72 144 17.7 122 103 85 66 47 - -
67 131 17.4 131 131 118 99 81 62 43
62 122 17.3 122 122 122 104 85 67 48
57 112 17.2 112 112 112 93 75 56 38
* These capacities are gross ratings. For net
capacity, deduct air blower motor, MBH = 3.415
x kW. Refer to the appropriate Blower Perfor-
mance Table for the kW of the supply air
blower motor.
† These ratings include condenser fan motors
and the compressor motors but not the supply
air blower motor.
