246646-YTG-C-0606
16 Unitary Products Group
TABLE 8: COOLING CAPACITY DH120 (10 TON) UNIT
Air On
Evap. Coil
Temperature of Air on Condenser Coil 85°F Temperature of Air on Condenser Coil 95°F
CFM
WB
(°F)
Tot.
Cap. *
(MBH)
Tot.
Input †
(kW)
Sensible Capacity (MBH) *
Return Dry Bulb (°F)
Tot.
Cap. *
(MBH)
Tot.
Input †
(kW)
Sensible Capacity (MBH) *
Return Dry Bulb (°F)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
3000
72 136 8.8 79 71 62 53 45 - - 126 9.4 79 70 61 53 44 - -
67 122 8.6 99 90 82 73 64 56 47 114 9.1 96 88 79 70 62 53 45
62 110 8.3 110 107 98 89 81 72 64 108 9.0 108 106 97 89 80 72 63
57 109 8.7 109 105 97 88 80 71 63 103 9.1 103 102 93 84 76 67 59
3500
72 140 8.9 88 78 68 58 48 - - 130 9.5 87 77 67 57 47 - -
67 126 8.7 110 100 89 79 69 59 49 118 9.1 106 96 86 76 66 56 46
62 114 8.4 114 112 107 97 87 77 67 112 9.0 112 111 106 96 86 76 65
57 112 8.7 112 110 106 96 86 76 66 106 9.1 106 106 101 91 81 71 61
4000
72 144 9.0 97 86 74 62 51 - - 134 9.5 96 84 72 61 49 - -
67 129 8.8 121 109 97 86 74 62 51 122 9.2 116 105 93 81 70 58 46
62 117 8.5 117 117 117 105 93 82 70 115 9.1 115 115 115 103 91 80 68
57 115 8.8 115 115 115 104 92 80 69 110 9.2 110 110 110 98 86 75 63
4500
72 151 9.1 106 93 80 66 53 - - 139 9.6 105 92 78 65 52 - -
67 135 8.9 131 118 105 91 78 65 52 126 9.3 124 114 101 87 74 61 48
62 122 8.6 122 122 122 109 96 82 69 120 9.2 120 120 119 106 93 79 66
57 121 8.9 121 121 121 107 94 81 67 114 9.3 114 114 114 100 87 74 61
5000
72 157 9.2 115 100 85 70 55 - - 144 9.7 114 99 84 69 54 - -
67 141 9.0 141 127 112 97 82 67 53 131 9.4 131 123 108 93 78 63 49
62 128 8.7 128 128 128 113 98 83 68 124 9.3 124 124 124 109 94 79 64
57 126 9.1 126 126 126 111 96 81 66 118 9.4 118 118 118 103 88 73 58
Temperature of Air on Condenser Coil 105°F Temperature of Air on Condenser Coil 115°F
3000
72 116 9.9 74 66 57 49 40 - - 106 10.4 70 61 53 44 36 - -
67 106 9.6 92 84 75 67 58 50 41 97 10.1 89 80 72 63 55 46 37
62 98 9.4 98 97 88 80 71 63 54 88 9.7 88 88 80 71 63 54 46
57 96 9.5 96 95 87 78 69 61 52 88 10.0 88 88 80 72 63 54 46
3500
72 120 10.0 82 72 62 52 42 - - 110 10.5 78 68 58 47 37 - -
67 109 9.7 101 92 82 72 62 52 42 100 10.2 96 88 78 68 58 48 38
62 101 9.4 101 101 96 86 76 66 56 91 9.8 91 91 87 77 67 57 47
57 99 9.6 99 99 94 84 74 64 54 91 10.1 91 91 87 77 67 57 47
4000
72 124 10.1 91 79 67 56 44 - - 114 10.6 86 74 62 51 39 - -
67 113 9.7 110 100 89 77 65 54 42 104 10.3 104 96 84 73 61 49 38
62 105 9.5 105 105 104 93 81 69 58 94 9.9 94 94 94 82 71 59 47
57 102 9.7 102 102 102 90 79 67 55 94 10.2 94 94 94 83 71 59 48
4500
72 126 10.1 99 86 73 60 46 - - 114 10.6 94 81 68 54 41 - -
67 115 9.8 114 107 96 83 70 56 43 104 10.3 104 100 92 78 65 52 39
62 107 9.6 107 107 107 93 80 67 54 94 10.0 94 94 94 81 68 54 41
57 104 9.8 104 104 104 91 78 64 51 95 10.3 95 95 95 81 68 55 42
5000
72 129 10.2 108 93 79 64 49 - - 114 10.7 103 88 73 58 43 - -
67 117 9.9 117 114 104 89 74 59 44 104 10.4 104 104 99 84 69 54 39
62 109 9.7 109 109 109 94 79 64 50 94 10.0 94 94 94 80 65 50 35
57 106 9.8 106 106 106 91 77 62 47 95 10.3 95 95 95 80 65 50 35
Temperature of Air on Condenser Coil 125°F
3000
72 97 10.8 66 57 48 40 31 - -
67 88 10.5 85 77 68 59 51 42 34
62 78 10.1 78 78 71 63 54 45 37
57 81 10.4 81 81 74 65 57 48 39
3500
72 100 11.0 73 63 53 43 33 - -
67 92 10.7 91 84 74 64 54 44 34
62 81 10.2 81 81 77 67 57 47 37
57 84 10.6 84 84 80 70 60 50 40
4000
72 104 11.1 80 69 57 46 34 - -
67 95 10.8 95 92 80 68 57 45 33
62 83 10.3 83 83 83 72 61 49 37
57 87 10.7 87 87 87 75 63 52 40
4500
72 101 11.1 89 76 62 49 36 - -
67 93 10.9 93 93 87 74 61 47 34
62 82 10.4 82 82 82 69 55 42 29
57 85 10.8 85 85 85 72 59 45 32
5000
72 99 11.2 97 82 67 52 38 - -
67 91 10.9 91 91 91 79 65 50 35
62 80 10.4 80 80 80 65 50 35 20
57 83 10.8 83 83 83 68 54 39 24
* These capacities are gross ratings. For net
capacity, deduct air blower motor, MBH = 3.415
x kW. Refer to the appropriate Blower Perfor-
mance Table for the kW of the supply air
blower motor.
† These ratings include condenser fan motors
and the compressor motors but not the supply
air blower motor.
