PCL/PJL Feature Dependencies/Caveats
All PJL commands must be in the first 2,500 bytes of the job.
To combine printer escape commands (not including PJL commands):
-
The first two characters after the
-
All alpha characters MUST be lowercase, except the final terminating character.
-
The commands are read left to right. Combine commands in the order you wish them
to execute.
For example, combine print 5 copies (
as
In case of duplicate commands, the last one requested takes precedence.
The @PJL SET COPIES takes precedence over the PCL Escape Command (
X>) to set copies. In general, a PJL command takes precedence over a PCL command.
Valid media sizes for duplexing are between 128.0 x 140.0mm and 320.0 x 483.0mm.
Valid media sizes for stapling include A4 (210 x 297mm), A3 (297 x 420mm), B5 (182 x
257mm), B4 (257 x 364mm), Executive (7.25 x 10.5"), Letter (8.5 x 11"), 8.5 x 13", Legal (8.5
x 14"), Tabloid (11 x 17"), 16K (194 x 267mm), 8K (267 x 388mm), 16K (195 x 270mm), 8K
(270 x 390mm) for Finisher A/B/C. For Finisher B/C, 8 x 10", 215 x 315mm, 11 x 15", A4
Cover, 9 x 11" are also valid.
PCL Fonts
The following PCL fonts are resident.
The commands in the table reference a 12-point font. If you wish to use any other point size,
change the 12v within the PCL Escape Command to the desired size (.25 – 999.75).
The commands listed use the default symbol set, Roman-8. To change the symbol set, you
include the alternate symbol set after the first
printer examples as a reference.
Font Name
PCL Escape Command
Albertus Medium
Albertus Extra Bold
Antique Olive
Antique Olive Bold
Antique Olive Italic
Arial
Arial Bold
Arial Italic
Arial Bold Italic
CG Times
CG Times Bold
CG Times Italic
CG Times Bold Italic
CG Omega
CG Omega Bold
CG Omega Italic
CG Omega Bold Italic
Clarendon Condensed
Coronet
Courier
Courier Bold
