TABLE 3: DNP024 COOLING CAPACITIES - 2 TON (CONT’D)
AIR ON
EVAPORATOR
COIL
TEMPERATURE OF AIR ON CONDENSER COIL
125°F
NET
CAP.
MBH
POWER
INPUT
KW
SENSIBLE CAPACITY
1
ENTERING DRY BULB, °F
CFM
WB
°F
86
83
80
77
74
71
68
600
72
19.8
2.6
13.8
12.1
10.4
8.7
7.0
#N/A
#NIA
67
17.8
2.5
17.6
15.9
14.2
12.5
10.8
9.1
7.4
62
17.4
2.5
17.4
17.5
15.8
14.1
12.4
10.7
9.0
57
17.6
2.5
17.6
17.6
16.0
14.3
12.6
10.8
9.1
700
72
20.7
2.6
15.3
13.3
11.3
9.2
7.2
#N/A
#N/A
67
18.6
2.5
19.0
17.4
15.4
13.4
11.4
9.4
7.3
62
18.2
2.5
18.2
18.2
17.2
15.2
13.1
11.1
9.1
57
18.5
2.6
18.5
18.5
17.3
15.3
13.3
11.3
9.2
800
72
21.6
2.6
16.8
14.5
12.2
9.8
7.5
#N/A
#N/A
67
19.4
2.6
20.4
19.0
16.6
14.3
12.0
9.6
7.3
62
19.0
2.6
19.0
19.0
18.5
16.2
13.9
11.5
9.2
57
19.3
2.6
19.3
19.3
18.7
16.4
14.0
11.7
9.4
900
72
21.8
2.7
18.0
15.3
12.7
10.0
7.4
#N/A
#N/A
67
19.7
2.6
20.1
19.9
17.3
14.7
12.0
9.4
6.7
62
19.2
2.6
19.2
19.2
19.0
16.3
13.7
11.0
8.3
57
19.5
2.6
19.5
19.5
19.2
16.5
13.9
11.2
8.6
1000
72
22.1
2.8
19.1
16.2
13.2
10.2
7.2
#N/A
#N/A
67
19.9
2.7
19.9
20.8
18.1
15.1
12.1
9.1
6.1
62
19.4
2.7
19.4
19.4
19.4
16.4
13.4,
10.5
7.5
57
19.7
2.7
19.7
19.7
19.7
16.7
13.7
10.8
7.8
1.
These capacities are net capacities (the indoor fan heat is deducted).
ALL SENSIBLE CAPACITY
