Chapter 4 Wireless Configuration
NWD210N User’s Guide
52
4.3.1.2 WPA-PSK/WPA2-PSK
Figure 30 Security Setting: WPA-PSK/WPA2-PSK
The following table describes the labels in this screen.
4.3.1.3 WPA/WPA2
The screen that displays when you select WPA or WPA2 differs, depending on the EAP Type
you select (TLS, PEAP or TTLS).
"
The procedure to configure WPA or WPA2 is different in Windows Vista. See
Section 4.6 on page 64 for information on setting up your NWD210N to use
WPA or WPA2 in Vista.
Back Click Back to go to the Site Survey screen to select and connect to another
network.
Next Click Next to confirm your selections and advance to the Summary screen. Refer
to Section 4.3.3 on page 55 .
Exit Click Exit to return to the Site Survey screen without saving.
Table 8 Security Setting: WEP (continued)
LABEL DESCRIPTION
Table 9 Security Setting: WPA-PSK/WPA2-PSK
LABEL DESCRIPTION
Encryption Type The encryption mechanisms used for WPA/WPA2 and WPA-PSK/WPA2-PSK are
the same. The only difference between the two is that WPA-PSK/WPA2-PSK uses
a simple common password, instead of user-specific credentials.
Select the encryption type (TKIP or AES) for data encryption.
Refer to
Section 3.2.1.3 on page 39 for more information.
Pre-Shared Key Type a pre-shared key (same as the AP or peer device) of between 8 and 63
case-sensitive ASCII characters (including spaces and symbols) or 64
hexadecimal characters.
Back Click Back to go to the Site Survey screen to select and connect to another
network.
Next Click Next to confirm your selections and advance to the Summary screen. Refer
to Section 4.3.3 on page 55 .
Exit Click Exit to return to the Site Survey screen without saving.
