POWERING UP
Operation
4 cables connect the back of the
Console to the computer.
• Power cable
• Video cable
• Keyboard cable
• Mouse cable
To connect the four cables:
• Turn off the computer and all
attached devices.
• Connect the video cable to the
video port on the back of the
computer.
• Insert the power plug into a properly
grounded electrical outlet.
WARNING: Be sure all electrical
power to the cabinet is off
before connecting any of the
cables.
WARNING: There is a key guide for
alignment on all the cables.
Be sure the cable plug and
receptacles are aligned
properly using the key
guide. Misalignment can
cause short circuiting.
INSTALLING CABLES
Switch the Console
monitor on by pushing
and releasing the power
switch marked.
Turn on the monitor and
then the computer.
