Maintenance Instructions

REPLACING/REPAIRING/

ADJUSTMENTS

Reinstall the blades following procedure in

CHECK-

ING/SERVICING for Sharpen Mower Blades in-

structions. If blades are replaced, always use

Walk-

er original equipment blades to ensure safety and

optimum performance. The quality and performance

of

replacement blades offered by other manufac-

turers cannot be guaranteed, they could be dan-

gerous.

  CAUTION

ALWAYS use genuine factory replace-

ment parts. Substitute parts CAN result

in product malfunction and possible in-

jury to the operator.

ADJUSTMENTS
Steering Levers
An adjustment range of approximately 3 in. (76 mm)

is available on the steering levers - the levers can be

adjusted forward or aft depending on the arm length

of the operator. The levers can be adjusted by loos-

ening the locknut at the pivot point and the locknut

holding the lever in position in the adjustment slide.

Adjust levers into most comfortable position and

tighten both locknuts.

Adjustment

Slide

Locknut

(Position)

Locknut

(Pivot Point)

Steering Lever Adjustment

Tilt-Up Deck Adjustable Stop

When the carrier frame hinge joint is properly ad-

justed, the deck lock levers should move in and out

of the engaged and disengaged positions freely. Ad-

justments are made by loosening the jam nut and

tightening or loosening the set screws on the Deck

Mount Pivot Brackets. Retighten the jam nut when

the adjustment is complete.

Jam Nut

Set Screw

Tilt-Up Deck Adjustable Stop

GHS Signal Horn Adjustment

(When Horn Sounds at Wrong Time)

The vertical position of the Grass-Pak

®

switch is

critical to make sure the catcher box does not over-

fill causing the delivery chute to clog. The vertical

position can be adjusted by bending the mounting

bracket for the Grass-Pak

®

switch.

1. Position the discharge chute so that it is point-

ing straight back.

a. Turn the ignition switch

ON and move the

blade clutch to the

ENGAGED position

(engine not running).

b. Open the catcher back door and monitor

the spout position (as it oscillates) and

move the blade clutch to the

DISENGAGED

position and turn the ignition switch to the

OFF position.
