Maintenance Instructions
LUBRICATION
50
Ident Lubrication No.
No. Location Type Places
Ident Lubrication No.
No. Location Type Places
1 Deck Caster Wheel Fork Pivot Grease 2
2 Deck Caster Wheel Bearing Grease 2
3 Tee Gearbox, Deck Oil* 1
4 Blade Drive Gearbox Oil* 2
5 Universal Joint Shaft Assembly Grease** 1
6 Pivot Assembly, Tilt-Up Deck Grease 4
7 Deck Support Arm Socket Grease 2
8 Body Hinge Point Oil 2
9 FSC Actuator Rod Pivot Pins Oil 2
10 FSC Lever Pivot Grease 1
11 FSC Lever Fork Grease 1
(Grease Slide Area)
12 (FSC) Friction Body Pivot Grease 1
13 Steering Lever Pivot Grease 4
14 Deck Support Arm Pivot Grease 2
15 Deck-to-PTO Coupling Grease 1
(Grease Slide Area)
16 Universal Joint Tube Assembly Grease** 1
17 Universal Joint Quick Connect Grease 1
Spline (Grease Slide Area)
18 Parking Brake Lever Grease 1
19 Gear Axle Oil*** 2
20 Belt Tightener Pivot, Grease 1
Jackshaft Drive
21 Clutch Actuator Push Rod Grease 2
22 PTO Clutch Lever Pivot Grease 1
23 Belt Tightener Pivot, Grease 1
PTO Clutch
24 Brake Actuator Rod and Brake Oil 3
Band Pivot Pins (Clevis)
25 Brake Actuator Pivot Grease 1
26 Catcher Hinge Point Oil 2
27 Choke Control Cable Ends Oil 2
28 Throttle Control Cable Ends Oil 2
29 Engine Oil Oil*** 1
30 Belt Tightener Pivot, Grease 1
Blower Drive (GHS Model Only)
31 Belt Tightener Pivot, Grease 1
Ground Drive
32 PTO Gearbox Dipstick Oil*** 1
33 Hydrostatic Drive Oil*** 2
34 Choke Control Pivot Oil 1
35 Throttle Control Pivot Oil 1
* Gearboxes are permanently lubricated and
sealed requiring no scheduled lubrication. Oil
level should be checked only when an oil leak
is noted. Refer to Mower Deck Gear box Lu-
brication in this section.
** Grease every eight (8) hours.
*** Refer to Gear Axle Lubrication, Engine Oil,
Tractor PTO Gearbox Lubrication, and Hy-
drostatic Transmission Fluid in this sec-
tion.
NOTE: DGHS42 Tilt-Up Deck is shown for reference.
For other Deck Lubrication Points, Refer to
Deck and Carrier Frame Illustrated Parts Man­
ual.
