Please Do Not Return This Product To The Store. Contact your local Wayne-Dalton dealer.
To find your Wayne-Dalton dealer; refer to your local yellow pages / business listings or go to Find a dealer area online at
www.wayne-dalton.com
23
Tools Needed:
INST
ALLA
TION
16
Torsion Spring Assembly
NOTE: Right and left hand is always
determined from inside the garage
looking out.
Facing the inside of the door, lay the
torsion tube on the floor. lay the spring
with the black color coded winding
cone and the red color coded cable
drum, at the left hand end of the tube.
lay the spring with the red color coded
winding cone and the black color coded
cable drum, at the right hand end of the
tube.
NOTE: Identify the springs provided as
either right hand wound (red winding
cone), which goes on the RIGhT haND
sIDE or left hand wound (black winding
cone), which goes on the lEFT haND
sIDE.
NOTE: The set screws used on all
torsion counterbalance winding cones
and cable drums, are now colored red.
DO NOT identify right and left hand by
the set screw color.
slide the nylon center bushing onto the
torsion tube followed by the springs.
The nylon center bushing and springs
must be positioned as shown.
With assistance, pick up the torsion
assembly and slide one end of the tube
through one end bearing bracket. lay
the torsion tube into the center bearing
bracket and slide the other end of the
tube into the opposite end bearing
bracket.
Position the torsion tube so that equal
amounts of the tube extend from each
end bearing bracket.
slide the red cable drum onto the left
end of the torsion tube. slide the black
cable drum onto the right end of the
torsion tube.
none
lEFT
ha
ND
WO
uND
bla
Ck
WINDING
CONE
lEFT
haND
sIDE
TORsION
TubE
RIG
hT
haND
WO
uND
RED
WINDING
CONE
RIG
hT
haND
sIDE
NylON CENTER
bRaCkET bushING
lEFT haND WOuND
blaCk WINDING CONE
lEFT haND sIDE
NylON CENTER
bRaCkET bushING
TORsION
TubE
RIGhT haND WOuND
RED WINDING CONE
RIGhT haND sIDE
TORsION
assEMbly
CENTER
bRaCkET
END
bEaRING
bRaCkET
TORsION
assEMbly
lEFT haND
CablE DRuM
RED
RIGhT haND
CablE DRuM
blaCk
