ASSISTANT AH-1070 User Manual
ASSISTANT Clock

POWER SUPPLY
This unit is designed to operate from AC
230V~50Hz household mains supply, The 9V
type 006p battery is used for clock back-up only.
RADIO OPERATION
1. To turn on, slide the Function switch (11)
to the “ON” position.
2. Slide the Band selector switch (1) to the
FM, AM position.
3. Adjust the Volume control (10) to the
desired volume level.
4. Turn the Tuning control (12) to the fre-
quency of the desired station.
5. To turn the radio off, slide the Function
switch (11) to the “OFF” position.
CLOCK SETTING
1. To set the hours, while holding the Time
set button (7) down, press the Hour set but-
ton (2) until the desired hour is displayed.
Release both buttons.
2. To set the minutes, while holding the
Time set button (7) down, press the Minutes
set button (3) until the correct time appears
on the display (8). Release both buttons.
WAKE TO RADIO OR BUZZER
1. Select the desired radio station and vol-
ume level.
2. Hold the Alarm set/off button (4) down
and press the Hour set button (2) to set the
desired alarm hour, and hold the Alarm set/
off button (4) and press the Minute set but-
ton (3) to your desired minute setting.
3. To wake to buzzer instead of radio, make
sure to turn the Volume control (10) off.
4. To turn the radio or buzzer off slide the
Function switch (11) to the “OFF” position or
press the Alarm set/off button (4).
english
– 2 –
english
LED CLOCK RADIO
Model AH-1070
english
– 3 –
english
SNOOZE REPEAT ALARM
1. When the buzzer sounds or the radio
turns on, pressing the Snooze button (9)
will turn off the buzzer or radio temporary.
Approximately 9 minutes later, the buzzer or
radio will turn on again.
2. To cancel the snooze operation, slide
the Function switch (11) to the “OFF” position
or press the Alarm set/off button (4).
SLEEP TO RADIO
1. Select the desired radio station.
2. Slide the Function switch (11) to the
“AUTO” or “OFF” position.
3. Press the Sleep button (6) and the clock
display will show 59 minutes as the default
sleep period. The sleep period can be reduced
as desired by pressing the minute set button
(3) while holding the Sleep button (6) down.
4. The sleep period can also be set up to
1hour 59 minutes by pressing the Hour set
button (2) once while holding the sleep but-
ton (6) down.
5. The radio will play for the desired period
and then turn itself off automatically.
6. To turn the radio off prior to the end of
the preset period, imply press the Snooze
button (9) once.
SLEEP AND WAKE TO RADIO
1. Select your desired radio station.
2. Slide the Function switch (11) to the
“AUTO” Position.
3. Set the desired wake-up time as de-
scribed above.
4. Press the Sleep button (6) and set the
desired sleep period.
ANTENNA
This radio has built-in ferrite antenna for
AM radio band and its reception is direction-
al. Therefore, changing the orientation of the
unit may improve the reception. The FM ra-
dio also has a flexible wire antenna on the
back of the unit, and it should be extended
to its full length for best reception.
english
– 4 –
english
english
– 6 –
english
english
– 7 –
english
english
– 5 –
english
english
– 1 –
english
OPERATION MANUAL
LOCATIONS OF RADIO
AND CONTROLS
1. Band selector switch
2. Hour set button
3. Minute set button
4. Alarm set off button
5. Dial scale
6. Sleep button
7. Time set button
8. Digital display
9. Snooze button
10. Volume control
11. Function control
12. Tuning control
WWW.TIWELL.COM
WWW.ASSISTANT.UA
